TA1600/2400/3200 User Manual
39/66
Figure 8-4 RADIUS Settings
Table 8-2 Description of RADIUS Settings
Items
Description
Enable RADIUS
Enable RADIUS on TA FXS Gateway.
Primary Server IP
Set IP address of the primary server.
Primary Server
Port
Default is 1813. Specifies the port to be used for the primary
RADIUS account.
Primary Server Key
Specifies the key to be used to authenticate the RADIUS
connection to the Primary server. The key is set according to
the RADIUS server.
Secondry Server IP
Set IP address of the primary server. The second sever will be
activated the primary one becomes unusable.
Secondry Server
Port
Default is 1813. Specifies the port to be used for the second
RADIUS account.
Secondry Server
Key
Specifies the key to be used to authenticate the RADIUS
connection to the second server. The key is set according to
the RADIUS server.
RADIUS Timeout
Specifies the number of seconds to wait for a response after
the RADIUS message is sent to the server. Default: 10
seconds.
The retransmission will be performed if there is no response
after the timeout.
RADIUS Retry
Times
Specifies the number of times the RADIUS messages will
send to the RADIUS server before giving up. Default: 3.
Call Out CDR
Whether to send "Call Out CDR" to RADIUS server or not.
Call In CDR
Whether to send "Call In CDR" to RADIUS server or not.
No Answer CDR
Whether to send "Call Out CDR" to RADIUS server or not.
