TA1600/2400/3200 User Manual
15/66
Other Settings
Figure 4-2 FXS Port Other Settings
Table 4-2 Description of FXS Port Other Settings
Follow Me
Choose the forward type and configure the relevant destination number. In different
conditions, the incoming calls to the account will be forwarded to different
destinations.
Always: always forward calls to the destination number.
No Answer: forward calls when no one answers the call.
When Busy: forward the call when the account is busy.
Features
Call Waiting
Check this option if the extension should have Call Waiting
capability. If this option is checked, the ―When busy‖ follow
me options will not be available.
DND
Don’t Disturb. When DND is enabled for an extension, the
extension will not be available.
