TA1600/2400/3200 User Manual
26/66
Note: We don’t’ recommend configuing this if you are not familiar with the code of call
status from the VoIP server.
5) T.38
Settings on this page is for the purpose of improving receiving and sending T.38 FAX.
Figure 5-8 T.38 Settings
Table 5-6 Description of T.38 Settings
Items
Description
Re-invite SDP Not Add T.38
Attributes
If set to Yes, SDP in re-invite packet will not add
T.38 attributes.
Error Correction
Re-invite SDP T38FaxUdpEc.
T.38 Max BitRate
Set T38 Max BitRate.
T.38 Support Modems
Choose the T.38 modems:
V27ter
V29
V17
V27ter + V29
V17 + V29
V17 + V27ter + V29
7) Advanced Settings
Figure 5-9 SIP Advanced Settings
