Graco PR70e [3/70] Models
![Graco PR70e [3/70] Models](/views2/1192947/page3/bg3.png)
Models
334135C 3
Models
Related Manuals
System MD2 Valve
Ratio
Air Motor
in. (cm)
Required
Line
Voltage
Machine
Operation
Voltage
Maximum
Working
Pressure
psi (MPa, bar)
Maximum
Air Inlet
Pressure
psi (MPa, bar)
24S054 1:1
3 (7.6)
100-240 V
50/60 Hz,
1 phase -
50 Watts
24 VDC 3000 (21, 207) 100 (0.7, 7)
24S055 10:1
24S056 1:1
4.5 (11.4)
24S057 10:1
MD2 Dispense Valve Manual
Part Description
312185 MD2 Valve, Instructions
312394 PR70 and PR70v Feed Systems, Instructions-Parts
