Инструкция по эксплуатации Страница: 1

Graco PR70f Инструкция по эксплуатации онлайн

334984C

Operation - Maintenance

PR70f

™

with Flow Control

Fixed ratio system for accurate metering, mixing, and dispensing of two-component

materials with capability to dispense beads of material. For professional use only.

Not approved for use in explosive atmospheres or hazardous locations.

3000 psi (21 MPa, 207 bar) Maximum Working Pressure

100 psi (0.7 MPa, 7 bar) Maximum Air Inlet Pressure

See page 3 for model information.

Important Safety Instructions

Read all warnings and instructions in this manual

and all related manuals listed on page 3. Save all

instructions.

PR70f Shown on Variable Ratio Chassis
