Grounding
10 334984C
Grounding
This product must be grounded. In the event of an elec-
trical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric cur-
rent. This product is equipped with a cord having a
grounding wire with an appropriate grounding plug. The
plug must be plugged into an outlet that is properly
installed and grounded in accordance with all local
codes and ordinances.
Improper installation of the grounding plug may result in
electric shock. When repair or replacement of the cord
or plug is required, do not connect the grounding wire to
either flat blade terminal. The wire with insulation having
an outer surface that is green with or without yellow
stripes is the grounding wire. Do not modify the plug
provided; if it does not fit the outlet, have the proper out-
let installed by a qualified electrician. Only connect the
product to an outlet having the same configuration as
the plug. Do not use an adapter with this product.
Installation
Unpacking
Inspect the shipping container carefully for damage.
Open the box and inspect the contents. There should
not be any loose or damaged parts in the container.
Contact the carrier promptly if there is damage.
Compare the packing slip against all the items in the
box. Report any shortage or other inspection problems.
immediately.
Remove the PR70f system components from the con-
tainer.
The equipment must be grounded to reduce the risk
of static sparking and electric shock. Electric or static
sparking can cause fumes to ignite or explode.
Improper grounding can cause electric shock.
Grounding provides an escape wire for the electric
current.
Avoid contact with electrical inter-connects when
connecting electric power to the machine. Avoid
contact with Krytox
™
on the pump shaft, PE tank lid,
and PE tank lid gasket. Contact with Krytox causes
flu-like symptoms. Read all manufacturer’s warning
and material SDS to know the specific hazards of
the material used.
NOTICE
Do not lift the PR70f by the tanks as this may result in
damage to the machine.
