Component Identification
334984C 7
Component Identification
This section provides a guide for identifying system
components. Contact your Graco distributor or Graco
Ohio Customer Service for assistance in designing a
system to suit your particular needs.
Accessories are available from Graco. Make certain all
accessories are adequately sized and pressure-rated
for your system.
Key:
A Dispense Valve
B Advanced Display Module (ADM)
C Static Mixer
D Shield Locking Screw
E Power Switch
FAir Filter
GAir Inlet
H Air Pressure Relief Switch
J Protective Shield
K Voltage-to-Pressure Regulator
L Snuff Back Adjustment Knob
M A and B Tanks (On-board polyethylene version shown)
N External Control Interface Connections
FIG. 1: Typical Fixed Ratio PR70f (Without Hoses)
A
B
D
E
C
F
G
H
J
K
L
M
N
