Related Manuals
334984C 3
Related Manuals
Models
NOTE
* These are basic PR70 models. Flow control would be added to these models based on your application.
Product Configuration
The PR70f offers a flow control feature that provides a
PR70 with the capability to dispense beads of material.
This flow control feature can only be used on PR70 con-
figurations that include the Advanced Display Module
(ADM).
Contact Graco Ohio Customer Service at
1-800-746-1334 to configure a PR70f for your applica-
tion. For general information about PR70 configurations,
refer to the Product Configurator section in the PR70
and PR70v with Advanced Display Module Operation -
Maintenance Instructions, manual 312759.
NOTE: The parts that differentiate the PR70f from a
standard PR70 are shown in Flow Control Parts on
page 60.
Hydracheck Option
The Hydracheck option regulates the speed or feed rate
of the pump. It is recommended that the Hydracheck
option is installed when using the flow control function.
Flow control performs best if the majority of the pump
restriction is external to the material flow (such as from
the Hydracheck adjustment) or is from a restriction in
the material path prior to the mixing point. See Figure 3
on page 8 for the location of the Hydracheck on the
PR70f.
Product Pump Selection
When selecting the pumps for the fixed ratio PR70f, you
need to know the material ratio, expected dispense flow
rate, and minimum programmed dispense amount. See
Appendix C - Product Pump Selection Guide on
page 67 for information that will help with selecting
pump sizes.
PR70 Operation and Parts Manuals
Part Description
312759
PR70
™
and PR70v
™
with Advanced Display Module
Operation and Maintenance Manual
312760 PR70 and PR70v Repair and Parts Manual
312394 PR70 and PR70v Feed Systems Manual
312761 PR70v Integrated Heat Instructions - Parts Manual
Dispense Valve Manual
Part Description
312185 MD2 Dispense Valve Instructions and Parts Manual
Part No.
Maximum Working Pressure
psi (MPa, bar)
Description
LC0262* 3000 (21, 207) PR70 with 3.0 in. (4.56 mm) Air Motor
LC0264* 3000 (21, 207) PR70 with 4.5 in. (10.26 mm) Air Motor
LC0242 3000 (21, 207) PR70v with 3.0 in. (4.56 mm) Air Motor
LC0244 3000 (21, 207) PR70v with 4.5 in. (10.26 mm) Air Motor
