Graco G250 [21/24] Kit mounting bracket
![Graco G3000HR [21/24] Kit mounting bracket](/views2/1193363/page21/bg15.png)
Dimensions
308778U 21
Part No. 258718
1/4-18 npt(f)
inlet/outlet
3.15 in.
(80 mm)
1.96 in.
(49.8 mm)
3.71 in.
(94.2 mm)
Solvent Meter
Mounting Holes (bottom
1.75 in.
(44.45 mm)
M6
TI14674b
2.36 in.
(60 mm)
TI14680a
Part No. 15U749
0.44 in. (11 mm) slots for
mounting the meter
Kit Mounting Bracket
TI18200a
2.40 in.
(61 mm)
3.25 in.
(83 mm)
4.40 in.
(112 mm)
1.25 in.
(32 mm)
