Component Identification
3A3101D 7
Component Identification
Numbered items in the key below correspond to the
numbers in the Parts Lists starting on page 36.
Key:
FIG. 1 Pump Components
21
8
12
1
20
13
17
22
18
1 Air Motor Housing
8 Air Piston Cylinder
12 Dust Shield
13 Fluid Cylinder
17 Inlet Valve Check
18 Outlet Valve Check
20 Priming Bleed Valve
21 Pump Stroke Adjuster
22 Timing Valve
