Graco 1:1 Extruder Инструкция по эксплуатации онлайн

Part No. 965119

1:1 Extruder President

Check-Mate

200 System, carbon steel

Part No. 570135

1:1 Extruder President

Check-Mate

200 System, stainless steel

2000 psi (14 MPa, 140 bar) Pump Maximum Working Pressure

90 psi (621 kPa, 6.3 bar) Pump Maximum Air Inlet Pressure

150 psi (1 MPa, 10 bar) Ram Maximum Air Inlet Pressure

Important Safety Instructions

Read all warnings and instructions in this

manual. Save these instructions.

Operation

1:1 Extruder

Table Of Contents

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Pressure Relief Procedure . . . . . . . . . . . . . . . . . . . . . . 5

Initial Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Dispensing Mixed Material . . . . . . . . . . . . . . . . . . . . . . 5

Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Part No. 965119 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Part No. 965119 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Part No. 570135 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Part No. 570135 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 10

Part No. 570135 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Part No. 965119 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Mounting Footprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Part No. 570135 and 965119 . . . . . . . . . . . . . . . . . . . 11

Graco Standard Warranty . . . . . . . . . . . . . . . . . . . . . . . . 12

Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Supply, metering and dispense system for 5 gallon (20 Liter) pails. For professional use

only.

Not approved for use in European explosive atmosphere locations.

310726H
