2 308017
List of Models
Maximum Air
Working Pressure
Maximum Fluid
Working Pressure
Model No. Description MPa bar psi MPa bar psi
222770 10:1 ratio Monarkr Pump, Series A
(UHMWPE/PTFE Packed)
1.2 12 180 12 124 1800
235626 10:1 ratio Monarkr Pump, Series A
(PTFE Packed)
1.2 12 180 12 124 1800
222768 20:1 ratio Presidentr Pump, Series A
(UHMWPE/PTFE Packed)
1.2 12 180 25 248 3600
237207 20:1 ratio stubby Presidentr Pump,
Series A (UHMWPE/PTFE Packed)
1.2 12 180 25 248 3600
246933 20:1 ratio Presidentr Pump, Series A
(Tuffstack Throat Packed)
1.2 12 180 25 248 3600
222769 34:1 ratio Senatorr Pump, Series A
(UHMWPE/PTFE Packed)
0.8 8 120 28 281 4080
224660 34:1 ratio Quiet Senatorr Pump,
Series A (UHMWPE/PTFE Packed)
0.8 8 120 28 281 4080
237492 34:1 ratio stubby Senatorr Pump,
Series A (UHMWPE/PTFE Packed)
0.8 8 120 28 281 4080
237780 34:1 ratio stubby Quiet Senatorr
Pump, Series A
(UHMWPE/PTFE Packed)
0.8 8 120 28 281 4080
222778 55:1 ratio Bulldogr Pump, Series A
(UHMWPE/PTFE Packed)
0.6 6.2 90 34 341 4950
222813 55:1 ratio Quiet Bulldogr Pump,
Series A (UHMWPE/PTFE Packed)
0.6 6.2 90 34 341 4950
237208 55:1 ratio stubby Bulldogr Pump,
Series A (UHMWPE/PTFE Packed)
0.6 6.2 90 34 341 4950
237779 55:1 ratio stubby Quiet Bulldogr
Pump, Series A
(UHMWPE/PTFE Packed)
0.6 6.2 90 34 341 4950
