3
English
3
Contents
How to read this manual
The names of displays, menus, and buttons in this manual are enclosed in brack-
ets. (e.g. [Collection] pane, [File] menu, [f])
Before start
Features ...........................................................................................................................4
What’s in the box .............................................................................................................4
Connections
Rear Panel .......................................................................................................................5
Connecting input terminals ...........................................................................................6
Connecting output terminals .........................................................................................6
Connecting to the control panel ....................................................................................7
Connecting a computer ..................................................................................................7
About the USB audio driver software ............................................................................7
About USB-MIDI channel setting ..................................................................................9
Operations
Control Panel .................................................................................................................11
Operating the DJ section..............................................................................................12
Operating the MC section ............................................................................................13
Operating the PA section .............................................................................................14
Additional information
Troubleshooting ............................................................................................................15
About the exemption clauses ......................................................................................15
Block Diagram...............................................................................................................16
Specifications ................................................................................................................17
Mounting on a rack conforming to EIA
standards
The screw holes on the left and right of the control panel of this unit match 5U size
of any EIA standard 19-inch rack. The maximum depth of this unit is 225.1 mm.
! Secure this unit with screws (not supplied) matching the rack.
! Do not install this unit directly above a power amplifier. Heat radiating from the
power amplifier may damage this unit. Also, noise (hum noise, etc.) may be
generated.
! When transporting this unit, remove it from the rack. Transporting this unit
without removing it from the rack may damage this unit.
! If you transport this unit without removing it from the rack, make sure vibration
or shock is not applied to this unit.
