Panasonic ER206 [3/28] Maintenance

This Beard/Hair Trimmer is for the

trimming and care of mustaches,

beards and hair. Trimming length can

be adjusted between 2 to 18mm. The

trimmer can be operated either from

an AC power source or on its own

rechargeable battery.

Parts identification

(see fig. 1)

A Switch

Slide up to turn on, slide down to

turn off.

B Charge Indicator Lamp

Lights when the unit is connected

with the adapter J to an AC

power source for charging.

C Main Blade

A precision 39mm-wide blade

which can be used with the comb

attachment E.

D Quick Adjust Dial

Turn the dial to a higher setting to

raise or lower the comb attach-

ment E to the desired length

(between 2 and 18mm).

(see fig. 2)

E Comb Attachment

Use this to control the trimming

length. (see fig. 3)

F Stationary Blade

G Moving Blade

H Cleaning Lever

Push this lever to remove bits of

hair caught between the station-

ary blade and the moving blade.

I Blade Block

Release to remove the blade

block from the housing to clean

or replace the blade. (see fig. 7)

J Adapter

Use this to connect the trimmer

to an AC power source for

recharging or for AC operation.

K Oil

Lubricate the space between the

stationary and moving blade with

2 or 3 drops of oil after use. (see

fig. 9)

L Cleaning Brush

Trimming length indicator

Indicator

Trimming Length

2.0mm

3.0mm

4.5mm

6.0mm

7.5mm

9.0mm

10.5mm

12.0mm

13.5mm

15.0mm

16.5mm

18.0mm

Operation

Rechargeable-battery operation

Charge the battery by plugging the

trimmer into an AC source using the

adapter. The switch should be set to

0·Charge during charging. An 8-hour

charge will provide approx. 50 min-

utes of use.

AC operation

Plug the trimmer into an AC power

source using the adapter with the

switch set to 0·Charge. Wait about

10 seconds, then switch the trimmer

on. After use, return the switch to

the 0·Charge position.

Trimming of Beard

Place the angled face of the comb

against the skin and cut the beard

by moving the trimmer in all direc-

tions to obtain a uniform cut. (see

fig. 4)

With curly facial hair, the comb

attachment may not cut all of the hair.

In this case, remove the comb attach-

ment and use a conventional comb to

draw out the remaining uncut hair.

(see fig. 5)

When shaping the beard, remove

the comb attachment. Place the

angled edge against the skin and

make the border of the beard even.

Maintenance

Blades

1. Brush out the cutting mechanism.

(see fig. 6)

2. Hold body of the trimmer with

Panasonic mark upwards, place

the thumb against the blades, and

push them away from the main

body. (see fig. 7)

3. Push down the cleaning lever to

raise the moving blade and brush

in between the blades. (see fig. 8)

4. Put a few drops of oil on the

blades. (see fig. 9)

Blade Life

Blade life will vary according to the

frequency and length of use. For

example, using the unit for 10min-

utes every 3 days, the life expectan-

cy is approximately 3 years. If cut-

ting efficiency is reduced substan-

tially despite proper maintenance,

the blades have exceeded their ser-

vice life and should be changed.

The replacement part no. is

WER9601Y.

Battery life

Battery life will vary according to the

frequency and length of use. If the

battery is charged 3 times a month,

the service life will be approximately

6 years. If the unit is left without

being charged for more than 6

months, the charge will drain from

the battery and their service life may

be shortened.

Therefore, even when not using reg-

ularly, it is recommended that the

unit be recharged at least once

every six months.
