- 2 -
Overview
Moxa’s EtherDevice™ EDS-305 are smart Ethernet switches that provide
an economical solution for your Ethernet connections. As an added bonus,
the built-in smart alarm function helps system maintainers monitor the
health of your Ethernet network.
The EDS-305 have a wide operating temperature range of -40 to 75°C,
and are designed to withstand a high degree of vibration and shock. The
rugged hardware design makes either model perfect for ensuring that
your Ethernet equipment can withstand critical industrial applications,
and complies with FCC and CE Standards.
NOTE
Throughout this Hardware Installation Guide, we use EDS as an
abbreviation for Moxa EtherDevice
Switch:
EDS = Moxa EtherDevice Switch
Package Checklist
Your EDS is shipped with the following items. If any of these items is
missing or damaged, please contact your customer service
representative for assistance.
• Moxa EtherDevice™ Switch
• Hardware Installation Guide
• Moxa Product Warranty booklet
• Protective caps for unused ports
Features
High Performance Network Switching Technology
• 10/100BaseT(X) (RJ45), 100BaseFX (SC/ST-type, Multi/Single
mode)
• IEEE802.3/802.3u/802.3x
• Store and Forward switching process type, with 1024 address entries
• 10/100M, Full/Half-Duplex, MDI/MDIX auto-sensing
Industrial Grade Reliability
• Power failure, port break alarm by relay output
• Redundant dual DC power inputs
Rugged Design
• Operating temperature range from 0 to 60°C, or extended operating
temperature from -40 to 75°C for “-T” models
• IP30, rugged high-strength case
• DIN-rail or panel mounting ability
WARNING
The
power for this product is intended to be supplied by a Listed
Power Supply, with output marked LPS, and rated to deliver 12 to
48 VDC at a maximum of 0.6A.
The DC
jack should be used with an LPS unit that is rated to
deliver 12 to 48 VDC at a minimum of 1.1A. The product should
not be disassembled by operators or service people.
