Overview

The EDS-210A series 10-port industrial Ethernet switches are equipped

with 1 Gigabit fiber optic Ethernet port, up to 8 10/100M copper ports,

and 4 100M fiber optic Ethernet ports, making it ideal for applications that

require high bandwidth data convergence and long-distance uplinks. The

EDS-210A series provides 12/24/48 VDC redundant power inputs, has a

rugged IP30-rated metal housing, and is DIN-rail mountable. These

switches are compliant with FCC/UL/CE standards and undergo a 100%

burn-in test to ensure that they fulfill the special needs of industrial

automation control applications. The EDS-210A series has a -10 to 60°C

operating temperature range and is also available with wide-temperature

operation (-40 to 75°C).

NOTE

Throughout this Hardware Installation Guide, we use

EDS

as an

abbreviation for Moxa EtherDevice Switch:

EDS = Moxa EtherDevice Switch

Package Checklist

Your EDS is shipped with the following items. If any of these items is

missing or damaged, please contact your customer service

representative for assistance.

• Moxa EtherDevice™ Switch

• Hardware installation guide

• Moxa product warranty booklet

• Protective caps for unused ports

Features

High Performance Network Switching Technology

• 10/100/1000BaseT(X) (EDS-210A-1GTX-1GSFP-4SFP only),

10/100BaseT(X) auto-negotiation speed, full/half duplex mode, auto

MDI/MDI-X connection, and 100Base SFP slot /1000Base SFP slot.

• IEEE 802.3 for 10BaseT, IEEE 802.3u for 100BaseT(X), IEEE 802.3ab

for 1000BaseT, and IEEE 802.3z for 1000BaseX.

• Store-and-forward switching process type.

Rugged Design

• Operating temperature range of -10 to 60°C, or extended operating

temperature of -40 to 75°C (T models only)

• IP30, rugged high-strength case

• DIN-rail or panel mounting available

• Redundant dual 12/24/48 VDC
