Overview

The EDS-G308 series is equipped with 8 Gigabit Ethernet ports and up to

2 fiber optic ports, making it ideal for applications that demand high

bandwidth. The EDS-G308 series provides an economical solution for

your industrial Gigabit Ethernet connection, and the built-in relay warning

function alerts maintainers when power failures or port breaks occur. The

EDS-G308 series includes 2 models: one with an operating temperature

range of 0 to 60°C, and the other one with an extended operating

temperature range of -40 to 75°C. These 2 models have passed a 100%

burn-in test to ensure that they fulfill the special needs of industrial

automation control. The EDS-G308 series can be easily installed with

DIN-Rail mounting as well as distribution boxes.

NOTE

Throughout this Hardware Installation Guide, we use EDS as an

abbreviation for Moxa EtherDevice Switch:

EDS = Moxa EtherDevice Switch

Package Checklist

Your EDS is shipped with the following items. If any of these items is

missing or damaged, please contact your customer service

representative for assistance.

• Moxa EtherDevice™ Switch

• Hardware Installation Guide

• Moxa Product Warranty booklet

• Protective caps for unused ports

Features

High Performance Network Switching Technology

• 10/100/1000BaseT(X) (RJ45), auto negotiation speed, F/H duplex

mode, and auto MDI/MDI-X connection, 100/1000 BaseSFP slot.

• IEEE 802.3/802.3u/802.3ab/802.3z/802.3x.

• Store and Forward switching process type, 8K MAC address entries.

Industrial Grade Reliablity

• Power failure, port break alarm by relay output

• Redundant dual AC/DC power inputs

Rugged Design

• Operating temperature range of 0 to 60°C, or extended operating

temperature of -40 to 75°C for (-T) models

• IP30, rugged high-strength case

• DIN-rail or panel mounting ability

• Redundant dual 12/24/48VDC or 18 to 30 VAC at 47 to 63 Hz Power

inputs
