2
Industrial Ethernet Solutions
© Moxa Inc. All Rights Reserved. Updated Apr. 24, 2014. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Ordering Information
Available Models Port Interface
Standard Temperature
(0 to 60˚C)
Wide Temperature
(-40 to 75˚C)
10/100BaseT(X)
100BaseFX
Multi-mode,
SC Connector
Multi-mode,
ST Connector
Single-mode,
SC Connector
EDS-405A/408A-PN EDS-405A/408A-PN-T
5/8 – – –
Side View Front Views Rear View DIN-Rail/Panel
Mounting Kit
30.0 (1.2)
13.1
(0.5)
15.1
(0.6)
25.4
(1.0)
9.0 (0.4)
105.0 (4.1)
53.6 (2.1)
45.8 (1.8)
46.0 (1.8)
44.0 (1.7)
30.5 (1.2)
66.8 (2.6) 48.3 (1.9)
7.8
(0.3)
7.8
(0.3)
35.0 (1.4)
39.5 (1.6) 46.6 (1.8) 23.6 (0.9)
Dimensions
Unit: mm (inch)
Environmental Limits
Operating Temperature:
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
Safety: UL 508, UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1**
Hazardous Location: UL/cUL Class I Division 2 Groups A/B/C/D, ATEX
Zone 2 Ex nC IIC
EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A
EMS:
EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3,
EN 61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3,
EN 61000-4-6 (CS) Level 3, EN 61000-4-8
Marine: DNV, GL
Traffic Control: NEMA TS2
Rail Traffic: EN 50121-4*
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
* EDS-405A/408A-PN
** EDS-408A-PN only
Note: Please check Moxa’s website for the most up-to-date certification status.
MTBF (mean time between failures)
Time:
EDS-405A-PN Series: 392,000 hrs
EDS-408A-PN Series: 363,000 hrs
Database: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Package Checklist
• EDS-405A-PN or EDS-408A-PN switch
• RJ45 to DB9 console port cable
• Protective caps for unused ports
• Documentation and software CD
• Hardware installation guide (printed)
• Warranty card
Optional Accessories (can be purchased separately)
MXview: Moxa industrial network management software with 50, 100, 250, 500, 1000, or 2000 nodes
EDS-SNMP OPC Server Pro: OPC server software that works with all SNMP devices
ABC-01: Configuration backup and restoration tool for managed Ethernet switches, 0 to 60°C
operating temperature
DR-4524/75-24/120-24: 45/75/120 W DIN-rail 24 VDC power supplies
MDR-40-24/60-24: 40/60 W DIN-rail 24 VDC power supplies, -20 to 70°C operating temperature
WK-46: Wall mounting kit
RK-4U: 4U-high 19” rack mounting kit
