Industrial Ethernet Solutions
1
www.moxa.com
EDS-405A/408A Series
Introduction
The EDS-405A/408A are entry-level 5 and 8-port managed Ethernet
switches designed especially for industrial applications. The switches
support a variety of useful management functions, such as Turbo Ring,
Turbo Chain, ring coupling, IGMP snooping, IEEE 802.1Q VLAN, port-
• Command Line Interface (CLI) for quickly configuring major
managed functions
• IPv6 Ready logo awarded (IPv6 Logo Committee certified)
• DHCP Option 82 for IP address assignment with different policies
• Support EtherNet/IP, Modbus/TCP and PROFINET* protocols for
device management and monitoring
• Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250
switches), and RSTP/STP for network redundancy
• IGMP snooping and GMRP for filtering multicast traffic
• Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network
planning
Specifications
5 and 8-port entry-level managed Ethernet switches
based VLAN, QoS, RMON, bandwidth management, port mirroring,
and warning by email or relay. The ready-to-use Turbo Ring can be set
up easily using the web-based management interface, or with the DIP
switches located on the top panel of the EDS-405A/408A switches.
• QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
• RMON for efficient network monitoring and proactive capability
• SNMPv1/v2c/v3 for different levels of network management
security
• Bandwidth management to prevent unpredictable network status
• Port mirroring for online debugging
* EDS-405A/408A-PN series only
Features and Benefits
› Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250
switches), and RSTP/STP for network redundancy
› IGMP Snooping, QoS, IEEE 802.1Q VLAN, and port-based VLAN
supported
› Easy network management by web browser, CLI, Telnet/serial
console, Windows utility, and ABC-01
Technology
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3x for Flow Control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1p for Class of Service
IEEE 802.1Q for VLAN Tagging
Protocols: IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/
Client, TFTP, SNTP, SMTP, RARP, RMON, HTTP, Telnet, Syslog, DHCP
Option 66/67/82, BootP, LLDP, PROFINET*, EtherNet/IP, Modbus/TCP,
IPv6, NTP Server/Client
MIB: MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Bridge MIB, RSTP
MIB, RMON MIB Group 1, 2, 3, 9
Flow Control: IEEE 802.3x flow control, back pressure flow control
*EDS-405A/408A-PN series only
Switch Properties
MAC Table Size: 2 K (EDS-405A), 8 K (EDS-408A)
Packet Buffer Size: 1 Mbit
Interface
RJ45 Ports: 10/100BaseT(X) auto negotiation speed, Full/Half duplex
mode, and auto MDI/MDI-X connection
Fiber Ports: 100BaseFX ports (SC/ST connector)
Console Port: RS-232 (RJ45 connector)
DIP Switches: Turbo Ring, Master, Coupler, Reserve
LED Indicators: PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL,
10/100M
Alarm Contact: 1 relay output with current carrying capacity of 1 A @
24 VDC
Optical Fiber
Table:
100BaseFX
Multi-mode Single-mode
Wavelength 1300 nm 1310 nm
Max. TX -10 dBm 0 dBm
Min. TX -20 dBm -5 dBm
RX Sensitivity -32 dBm -34 dBm
Link Budget 12 dB 29 dB
Typical Distance
5 km
a
4 km
b
40 km
c
Saturation -6 dBm -3 dBm
a. 50/125 μm, 800 MHz*km fiber optic cable
b. 62.5/125 μm, 500 MHz*km fiber optic cable
c. 9/125 μm single-mode fiber optic cable
