- 16 -
LED
Color
Status
Description
PWR1 Amber
On
Power is being supplied to the main
module’s power input PWR1.
Off
Power is not being supplied to the main
module’s power input PWR1.
PWR2 Amber
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
MSTR/
HEAD
Green
On
1. The switch is set as the Master of the
Turbo Ring, or as the Head of the
Turbo Chain.
2. POST H.W. Fail (+Stat on and Fault
blinking).
Blinking
1. The switch has become the Ring
Master of the Turbo Ring.
2. The switch has become the Head of
the Turbo Chain, after the Turbo Ring
or Turbo Chain has gone down.
3. The switch is set as the
Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. The switch is not the Master of this
Turbo Ring.
2. This switch is set as a Member of the
Turbo Chain.
CPLR/
TAIL
Green
On
1. The switch’s coupling function is
enabled to form a back-up path.
2. The switch is set as the Tail of the
Turbo Chain.
3. POST S.W. Fail (+Stat on and Fault
blinking)
Blinking
1. Turbo Chain is down.
2. The switch is set as Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. This switch has disabled the coupling
function.
2. This switch is set as a Member of the
Turbo Chain.
FAULT +
MSTR/HEAD +
CPLR/TAIL
Rotate
Blinking
Sequentially
ABC-02-USB is importing/exporting files.
STATE +
FAULT +
MSTR/HEAD +
CPLR/TAIL
Blinking
Switch is being discovered/located by
MXview (twice per second).
10M
(TP)
Green
On
TP port’s 10 Mbps link is active.
Blinking
Data is being transmitted at 10 Mbps.
Off
TP port’s 10 Mbps link is inactive.
100M
(TP/
Fixed
FX)
Green
On
TP/Fixed FX port’s 100 Mbps link is active.
Blinking
Data is being transmitted at 100 Mbps.
Off
TP/Fixed FX port’s 100 Mbps link is
inactive.
