- 15 -
“Turbo Ring V2” DIP Switch Settings
DIP 1
DIP 2
DIP 3
DIP 4
ON: Enables the
default “Ring
Coupling
(backup)” port
when DIP switch
3 is already
enabled.
ON: Enables this
EDS as the Ring
Master.
ON: Enables the
default “Ring
Coupling” port.
ON: Activates
DIP switch 1, 2,
and 3 to
configure “Turbo
Ring V2”
settings.
OFF: Enables the
default “Ring
Coupling
(primary)” port
when DIP switch
3 is already
enabled.
OFF: This EDS
will not be the
Ring Master.
OFF: Do not use
this EDS as a ring
coupler.
OFF: DIP
switches 1, 2,
and 3 will be
disabled.
NOTE
You must enable the Turbo Ring function first before using the
DIP switch to activate the Master and Coupler functions.
NOTE
If you do not enable any of the EDS-518E series switches to be
the Ring Master, the Turbo Ring protocol will automatically
choose the
EDS-518E series
with the smallest MAC address range
to be the Ring Master. If you accidentally enable more than one
EDS
-518E series to be the Ring Master, these EDS-518E series
switches will auto
-negotiate to determine which one will be the
Ring Master.
LED Indicators
The front panel of the Moxa EDS-518E has several LED indicators. The
function of each LED is described in the following table:
LED
Color
Status
STATE
Green
On
The system passed the self-
Blinking
being reset.
• Once every two seconds: ABC-02-
Red On
The system failed self-diagnosis on
boot-up.
• RAM Test Fail / System Info. Read Fail
/ Switch Initial Fail / PTP PHY Error.
(+ Green MSTR lit on : HW FAIL)
• FW Checksum Fail / Uncompress Fail.
FAULT
Red On
2. ABC Loading/Saving Fail.
3. The port is
ingress multicast and broadcast
packets exceed the ingress rate limit.
4. Incorrect loop connection in a single
switch.
5. Invalid Ring port connection.
