Moxa Managed Ethernet Switches Featured Functions
3-55
Current Active IGMP Streams
This page displays the multicast stream forwarding status. It allows you to view the status per VLAN ID.
Stream Group: Multicast group IP address
Stream Source: Multicast source IP address
Port: Which port receives the multicast stream
Member ports: Ports the multicast stream is forwarded to.
NOTE
The IGMP stream table is supported only in Layer 3 switches
Static Multicast MAC Addresses
Layer 2 switch page
