www.moxa.com

info@moxa.com

Industrial Ethernet Solutions

EDS-510A Series

The EDS-510A Gigabit managed redundant Ethernet switch is equipped

with up to 3 Gigabit Ethernet ports, making it ideal for building a

Gigabit Turbo Ring, but leaving a spare Gigabit port for uplink use.

The Ethernet redundant Turbo Ring and Turbo Chain (recovery time

< 20 ms), RSTP/STP, and MSTP can increase system reliability and

• Command Line Interface (CLI) for quickly conﬁguring major

managed functions

• IPv6 Ready logo awarded (IPv6 Logo Committee certiﬁed)

• Software-based IEEE 1588 PTPv2 (Precision Time Protocol) for

precise time synchronization of networks

• DHCP Option 82 for IP address assignment with different policies

• Supports EtherNet/IP and Modbus/TCP protocols for device

management and monitoring

• Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250

switches), RSTP/STP, and MSTP for network redundancy

• IGMP snooping and GMRP for ﬁltering multicast trafﬁc

• Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network

7+3G-port Gigabit managed Ethernet switches

the availability of your network backbone. The EDS-510A series is

designed especially for communication demanding applications such

as process control, shipbuilding, ITS, and DCS systems, which can

benefit from a scalable backbone construction.

planning

• QoS (IEEE 802.1p/1Q) and TOS/DiffServ to increase determinism

• Port Trunking for optimum bandwidth utilization

• TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance

network security

• SNMPv1/v2c/v3 for different levels of network management

• RMON for efﬁcient network monitoring and proactive capability

• Bandwidth management prevents unpredictable network status

• Lock port function for blocking unauthorized access based on MAC

address

• Automatic warning by exception through e-mail, relay output

Features and Beneﬁts

Introduction

Speciﬁcations

› 2 Gigabit Ethernet ports for redundant ring and 1 Gigabit Ethernet

port for uplink solution

› Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250

switches), RSTP/STP, and MSTP for network redundancy

› TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance

network security

› Easy network management by web browser, CLI, Telnet/serial

console, Windows utility, and ABC-01

Technology

Standards:

IEEE 802.3 for 10BaseT

IEEE 802.3u for 100BaseT(X) and 100BaseFX

IEEE 802.3ab for 1000BaseT(X)

IEEE 802.3z for 1000BaseX

IEEE 802.3x for Flow Control

IEEE 802.1D-2004 for Spanning Tree Protocol

IEEE 802.1w for Rapid STP

IEEE 802.1s for Multiple Spanning Tree Protocol

IEEE 802.1Q for VLAN Tagging

IEEE 802.1p for Class of Service

IEEE 802.1X for Authentication

IEEE 802.3ad for Port Trunk with LACP

Protocols: IGMPv1/v2, GMRP, GVRP, SNMPv1/v2c/v3, DHCP Server/

Client, BootP, TFTP, SNTP, SMTP, RARP, RMON, HTTP, HTTPS,

Telnet, Syslog, DHCP Option 66/67/82, SSH, SNMP Inform, EtherNet/

IP, Modbus/TCP, LLDP, IEEE 1588 PTPv2, IPv6, NTP Server/Client

MIB: MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB,

Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9

Flow Control: IEEE 802.3x ﬂow control, back pressure ﬂow control

Switch Properties

Priority Queues: 4

Max. Number of Available VLANs: 64

VLAN ID Range: VID 1 to 4094

IGMP Groups: 256

MAC Table Size: 8 K

Packet Buffer Size: 1 Mbit

Interface

Fiber Ports: 1000BaseSFP slot

RJ45 Ports: 10/100BaseT(X) or 10/100/1000BaseT(X) auto negotiation

speed

Console Port: RS-232 (RJ45 connector)

DIP Switches: Turbo Ring, Master, Coupler, Reserve

LED Indicators: PWR1, PWR2, FAULT, 10/100M (TP port), 1000M

(Gigabit port), MSTR/HEAD, CPLR/TAIL
