Moxa Managed Ethernet Switches Featured Functions

3-80

Parameters Tolerance

Temperature (°C) ± 3°C

Voltage (V)

± 0.1V

Tx power (dBm) ± 3dB

Rx power (dBm) ± 3dB

Using the MAC Address Table

This section explains the information provided by the Moxa switch’s MAC address table.

The MAC Address table can be configured to display the following Moxa switch MAC address groups, which are

selected from the drop-down list:

ALL Select this item to show all of the Moxa switch’s MAC addresses.

ALL Learned Select this item to show all of the Moxa switch’s Learned MAC addresses.

ALL Static Lock Select this item to show all of the Moxa switch’s Static Lock MAC addresses.

ALL Static Select this item to show all of the Moxa switch’s Static, Static Lock, and Static

Multicast MAC addresses.

ALL Static Multicast Select this item to show all of the Moxa switch’s Static Multicast MAC addresses.

Port x Select this item to show all of the MAC addresses dedicated ports.

The table displays the following information:

MAC This field shows the MAC address.

Type This field shows the type of this MAC address.

Port This field shows the port that this MAC address belongs to.

Using Access Control List

NOTE

Access Control Lists are available in Moxa Layer 3 switches.

Access control lists (ACL) increase the flexibility and security of networking management.

ACL provides traffic filter capabilities for ingress or egress packets. Moxa access control list helps manage filter

criteria for diverse protocols and allows users to configure customized filter criteria. For example, users can

deny access to specific source or destination IP/MAC addresses.

The Moxa access control list configuration interface is easy-to-use. Users can quickly establish filtering rules,

manage rule priorities, and view overall settings in the display page.
