Industrial Secure Router User's Manual Getting Started
2-5
2. The web login page will open. Select the login account (Admin or User) and enter the Password (the same
as the Console password), and then click Login to continue. Leave the Password field blank if a password
has not been set.
NOTE
The default password for the EDR series with firmware v3.0 and later is “moxa”. For previous firmware
versions, the default password is blank. For greater security, please change the default password after the
first l
og in.
You may need to wait a few moments for the web page to be downloaded to your computer. Use the menu tree
on the left side of the window to open the function pages to access each of the router’s functions.
