CLI Command Set User's Manual Interface and Routing Functions
2-4
VRRP
Category Commands
VRRP Global Settings router(config)# vrrp enable
router(config)# no vrrp enable
VRRP Interface Settings Note:
These settings are in interface configuration mode
router(config-if)# vrrp enable
router(config-if)# no vrrp enable
router(config-if)# vrrp virtual-ip ip-address
router(config-if)# vrrp vrid virtual-router-ID
router(config-if)# vrrp priority priority
router(config-if)# vrrp preemption
router(config-if)# no vrrp preemption
router(config-if)# vrrp track-interface {lan | wan1 | wan2}
router(config-if)# no vrrp track-interface {lan | wan1 | wan2}
Display settings router# show vrrp
Traffic Prioritization
Category Commands
Enable/Disable
Priority settings
router(config)# traffic priority interface {wan1 | wan2 | lan}
router(config-traffic-priority)# max-bw kbps
router(config-traffic-priority)# default-priority {0 | 1 | 2 | 3}
router(config-traffic-priority)# priority {0 | 1 | 2 | 3} max-bw kbps min-bw kbps
router(config)# no traffic priority interface {wan1 | wan2 | lan}
Create/Enter policy
configuration mode
Default: enable
router(config)# traffic policy {outgoing | incoming} index
Policy settings Default:
The default value of priority is 0. The default value of mode is IP. The default values
of protocol, IP, port and interface are all. The policy enables by default.
router(config-traffic-policy)# priority {0 | 1 | 2 | 3}
router(config-traffic-policy)# mode {IP | MAC}
router(config-traffic-policy)# protocol {all | tcp | udp | icmp}
router(config-traffic-policy)# src-ip all
router(config-traffic-policy)# src-ip single ip-address
router(config-traffic-policy)# src-ip range ip-address1 ip-address2
router(config-traffic-policy)# dst-ip all
router(config-traffic-policy)# dst-ip single ip-address
router(config-traffic-policy)# dst-ip range ip-address1 ip-address2
router(config-traffic-policy)# src-port all
router(config-traffic-policy)# src-port single port
router(config-traffic-policy)# src-port range port1 port2
router(config-traffic-policy)# dst-port all
router(config-traffic-policy)# dst-port single port
router(config-traffic-policy)# dst-port range port1 port2
router(config-traffic-policy)# src-mac mac-address
router(config-traffic-policy)# interface {all | wan1 | wan2 | lan}
Enable/Disable/Delete
policy
router(config)# traffic policy {outgoing | incoming} index {enable | disable}
router(config)# no traffic policy {outgoing | incoming} index
