Industrial Network Security and Management
1
www.moxa.com
FINALISTS
EDR-810 Series
The EDR-810 is a highly integrated industrial multiport secure router
with firewall/NAT/VPN and managed Layer 2 switch functions. It is
designed for Ethernet-based security applications in sensitive remote
control or monitoring networks, and it provides an electronic security
perimeter for the protection of critical cyber assets such as pumping/
treatment systems in water stations, DCS systems in oil and gas
applications, and PLC/SCADA systems in factory automation. The
EDS-810 series includes the following cybersecurity features:
• Firewall/NAT: Firewall policies control network traffic between
different trust zones, and Network Address Translation (NAT)
shields the internal LAN from unauthorized activity by outside
hosts.
• VPN: Virtual Private Networking (VPN) is designed to provide
users with secure communication tunnels when accessing a
8+2G multiport industrial secure router with switch/firewall/NAT/VPN
Specifications
Introduction
private network from the public Internet. VPNs use IPSec (IP
Security) server or client mode for encryption and authentication of
all IP packets at the network layer to ensure confidentiality and
sender authentication.
The EDR-810’s “WAN Routing Quick Setting” provides an easy way
for users to set up WAN and LAN ports to create a routing function
in four steps. In addition, the EDR-810’s “Quick Automation Profile”
gives engineers a simple way to configure the firewall filtering function
with general automation protocols, including EtherNet/IP, Modbus TCP,
EtherCAT, FOUNDATION Fieldbus, and PROFINET. Users can easily
create a secure Ethernet network from a user-friendly web UI with a
single click, and the EDR-810 is capable of performing deep Modbus
TCP packet inspection. Wide temperature range models that operate
reliably in hazardous, -40 to 75°C environments are also available.
Award-winning Product
› 8+2G all-in-one firewall/NAT/VPN/router/switch
› Build up secure remote access tunnel with VPN
› Protect critical assets by stateful firewall
› Inspect industrial protocol with PacketGuard technology
› Easy network setup with network address translation (NAT)
› RSTP/Turbo Ring redundant protocol enhances network
redundancy
› -40 to 75°C operating temperature range (T model)
› ISA99 / IEC 62443 / NERC CIP compliance
› Check firewall settings with intelligent SettingCheck feature
Technology
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
IEEE 802.1Q for VLAN tagging
IEEE 802.3ad for port trunk
Protocols: SNMP v1/v2c/v3, DHCP server/client, TFTP, NTP/SNTP
server/client, HTTP, HTTPS, Telnet, SSH, IPSec, L2TP, IGMP v1/v2/v3,
QoS/CoS/ToS, Radius, RSTP/STP, LLDP, DDNS, Proxy ARP
Routing: Static routing, RIP V1/V2, OSPF
Throughput: 10000 packets per second (max. 100 Mbps)
Routing Redundancy: VRRP
Multicast Routing: Static, DVMRP, PIM-SM/SSM
Broadcast Forwarding: IP directed broadcast, broadcast forwarding
Redundancy: STP/RSTP, Turbo Ring V2, Ring Coupling, and Dual
Homing
Flow Control: IEEE 802.3x flow control, back pressure flow control
Security Functions
Firewall:
Features:
•Statefulinspection
•Routerrewallandtransparent(bridge)rewall
•Filter:IPandMACaddress,ports,ICMP,DDoS,Ethernetprotocols
•DeepPacketInspection:ModbusTCP/UDP
•QuickAutomationProles:EtherCAT,EtherNet/IP,FOUNDATION
Fieldbus, LonWorks, Modbus/TCP, PROFINET, IEC 60870-104, DNP,
FTP, SSH, Telnet, HTTP, IPSec, L2TP, PPTP, RADIUS
Throughput: Max. 10000 packets per second (Max. 100 Mbps)
DoS and DDoS Protection: Null Scan, Xmas Scan, NMAP-Xmas Scan,
SYN/FIN Scan, FIN Scan, NMAP-ID Scan, SYN/RST Scan, NEW-
Without-SYN Scan, ICMP-Death, SYN-Flood, ARP-Flood
NAT: N-to-1, 1-to-1, bidirectional 1-to-1, and port forwarding
