Moxa EDR-810-VPN-2GSFP-T [3/5] Ordering information

Industrial Network Security and Management

www.moxa.com

Ordering Information

Dimensions

Side View Front View Rear View DIN-Rail/Panel-

Mounting Kit

Unit: mm (inch)

44 (1.73)

30.5 (1.20)7.65 (0.30)

20 (0.79)

100 (3.94)

63.8 (2.51)

135 (5.23)

143.7 (5.66)

105 (4.13)

46 (1.81)

53 (2.09)

18 (0.71)

51.6 (2.03)

34 (1.34)

42.8 (1.69)

67 (2.64)

Available Models

EDR-810-2GSFP:8+2G-portindustrialmultiportsecurerouterwithrewall/NAT,-10to60°Coperating

temperature

EDR-810-2GSFP-T:8+2G-portindustrialmultiportsecurerouterwithrewall/NAT,-40to75°Coperating

temperature

EDR-810-VPN-2GSFP:8+2G-portindustrialmultiportsecurerouterwithrewall/NAT/VPN,-10to60°C

operating temperature

EDR-810-VPN-2GSFP-T:8+2G-portindustrialmultiportsecurerouterwithrewall/NAT/VPN,-40to75°C

operating temperature

Note: The EDR-810 series supports 1000BaseSFP slots. See the SFP-1G series Gigabit Ethernet SFP module product datasheet for more information.

Optional Accessories (can be purchased separately)

ABC-02-USB: Automatic Backup Conﬁgurator

DR-4524/75-24/120-24: 45/75/120 W DIN-rail 24 VDC power supplies

MDR-40-24/60-24: 40/60 W DIN-rail 24 VDC power supplies, -20 to 70°C operating temperature

WK-51-01: Wall-mounting kit, 2 plates with 6 screws

RK-4U:4U-high19-inchrack-mountingkit

Package Checklist

• EDR-810 industrial secure router

• Serial Cable: CN20070

• Documentation and software CD

• Hardware installation guide (printed)

• Warranty card
