Moxa EDR-810-VPN-2GSFP-T [2/5] Interface

Moxa EDR-810-2GSFP-T [2/5] Interface
Industrial Network Security and Management
2
www.moxa.com
IPSec VPN:
Protocols:
•IPSec
•L2TP(server)
•PPTP(client)
Encryption:
•DES,3DES,AES-128,AES-192,AES-256
Authentication:
•RSA(keysize:1024-bit,2048-bit)
•X.509v3certicate
•MD5andSHA(SHA-256)
Throughput:
•Max.17Mbps(Conditions:AES-256,SHA-256)
Concurrent VPN Tunnels:
•Max.10IPSecVPNtunnels
OpenVPN:
Protocols:
•OpenVPN(clientandserver),UDPandTCP
•Tunnelmode(routing)andTAPmode(bridge)
Encryption:
•BlowshCBC,DESCBC,DES-EDE3CBC,AES-128/192/256CBC
Authentication:
•UserpasswordbyMD5andSHA1
Throughput:
•Max.5Mbps
Concurrent VPN Tunnels:
•Servermode:max.5externalclients
•Clientmode:max.2externalservers
Real-Time Firewall / VPN Event Log:
•EventType:FirewallEvent,VPNEvent,SystemSecurityEvent
•Media:Localstorage,Syslogserver,andSNMPtrap
Switch Properties
Max. Number of VLANs: 16
VLAN ID Range:1to4094
IGMP Groups: 256
Interface
RJ45 Ports: 10/100BaseT(X) auto negotiation speed
Fiber Ports: 1000BaseSFP slot
Console Port: Web/Telnet/SSH/CLI, and RS-232 serial console
RESET button: Reset to default settings
LED Indicators: STATE, PWR1, PWR2, FAULT, 10/100/1000M
Alarm Contact: One relay output with current-carrying capacity of 1 A
@ 24 VDC
Digital Inputs: 1 2-contact terminal block
•+13to+30Vforstate“1”
•-30to+3Vforstate“0”
•Max.inputcurrent:8mA
Power Requirements
Input Voltage: 12/24/48 VDC, redundant dual inputs
Input Current: 0.32 A @ 24 V
Overload Current Protection: Present
Connection: Removable terminal block
Reverse Polarity Protection: Present
Physical Characteristics
Housing: Metal
Dimensions: 53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in)
Weight: 830 g (2.10 lb)
Installation: DIN-rail mounting, wall mounting (with optional kit)
Environmental Limits
Operating Temperature:
Standard Models: -10 to 60°C (14 to 140°F)
Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity:5to95%(non-condensing)
Standards and Certifications
Safety: UL 508
EMC: EN 55022/24
Hazardous Location: UL/cUL Class I Division 2 Groups A/B/C/D
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV
IEC 61000-4-6 CS: Signal: 10 V
IEC 61000-4-8
Rail Traffic: EN 50121-4
Transportation: NEMA TS2
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Note: Please check Moxa’s website for the most up-to-date certification status.
MTBF (mean time between failures)
Time:981,954hrs
Standard: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
