Industrial Ethernet Solutions
1
www.moxa.com
IKS-G6524A/G6824A Series
Introduction
Process automation and transportation automation applications
combine data, voice, and video, and consequently require high
performance and high reliability. The IKS-G6524A/G6824A series full
Gigabit backbone switches are equipped with 24 Gigabit Ethernet
ports, and support Layer 3 routing functionality to facilitate the
deployment of applications across networks, making them ideal for
large scale industrial networks. The IKS-G6524A/G6824A’s full Gigabit
24G-port Layer 2 / Layer 3 full Gigabit managed Ethernet switches
capability increases bandwidth to provide high performance and the
ability to quickly transfer large amounts of video, voice, and data
across a network. The switches support the Turbo Ring, Turbo Chain,
and RSTP/STP redundancy protocols, and are fanless and come with
an isolated redundant power supply to increase system reliability and
the availability of your network backbone.
• Layer 3 switching functionality to move data and information
across networks (IKS-G6824A series)
• Command line interface (CLI) for quickly configuring major
managed functions
• Supports advanced VLAN capability with Q-in-Q tagging
• Software based IEEE 1588 PTPv2 (Precision Time Protocol) for
time synchronization of networks
• DHCP Option 82 for IP address assignment with different policies
• Support EtherNet/IP and Modbus/TCP protocols for device
management and monitoring
• Compatible with EtherNet/IP and PROFINET protocols for
transparent data transmission
• Redundant Gigabit Turbo Ring and Turbo Chain (recovery time <
50 ms @ 250 switches), RSTP/STP, and MSTP for network
redundancy
• IGMP snooping and GMRP for filtering multicast traffic
• IEEE 802.1Q VLAN and GVRP protocol to ease network planning
• QoS (IEEE 802.1p/1Q and TOS/DiffServ) to increase determinism
• Port Trunking for optimum bandwidth utilization
• TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance
network security
• Access control lists (ACL) increase the flexibility and security of
network management (IKS-G6824A series)
• SNMPv1/v2c/v3 for different levels of network management
• RMON for efficient network monitoring and proactive capability
• Bandwidth management prevents unpredictable network status
• Lock port function for blocking unauthorized access based on MAC
address
• Port mirroring for online debugging
• Automatic warning by exception through e-mail, relay output
• Digital inputs for integrating sensors and alarms with IP networks
• Redundant, dual AC power inputs
Features and Benefits
› Layer 3 routing interconnects multiple LAN segments
(IKS-G6824A series)
› 24 Gigabit Ethernet ports
› Up to 24 optical fiber connections (SFP slots)
› Fanless, -40 to 75°C operating temperature range (T models)
› Turbo Ring and Turbo Chain (recovery time < 50 ms @ 250
switches), RSTP/STP, and MSTP for network redundancy
› Isolated redundant power inputs with universal 110/220 VAC
power supply range
› Supports MXstudio for easy, visualized industrial network
management
› V-ON™ ensures millisecond-level multicast data and video
network recovery
