Industrial Ethernet Solutions
2
www.moxa.com
Specifications
Technology
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseSX/LX/LHX/ZX
IEEE 802.3x for Flow Control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid Spanning Tree Protocol
IEEE 802.1s for Multiple Spanning Tree Protocol
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP
Software Features
Management: IPv4/IPv6*, SNMP v1/v2c/v3, LLDP, Port Mirror, DDM,
RMON, DHCP Server/Client, DHCP Option 66/67/82, BootP, TFTP,
SMTP, RARP, Telnet, Syslog, SNMP Inform, Flow Control, Back
Pressure Flow Control
*IPv6 only applies to IKS-G6524A series products.
Filter: 802.1Q VLAN, GVRP, IGMP v1/v2/v3, GMRP
Redundancy Protocols: STP, RSTP, MSTP, Turbo Ring v1/v2, Turbo
Chain, Link Aggregation
Security: RADIUS, TACACS+, SSL, SSH, Broadcast Storm Protection,
Port Lock, Access Control Lists (IKS-G6824A only)
Unicast Routing: Static Routing, RIPV1/V2, OSPF (IKS-G6824A series)
Multicast Routing: DVMRP, PIM-DM, PIM-SM, PIM-SSM (IKS-
G6824A series)
Time Management: SNTP, NTP Server/Client, IEEE 1588v2 PTP
(software-based)
Industrial Protocols: EtherNet/IP, Modbus/TCP, PROFINET
MIB: MIB-II, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, Bridge
MIB, RSTP MIB, RMON MIB Groups 1, 2, 3, 9
Routing Redundancy: VRRP (IKS-G6824A series)
Switch Properties
Priority Queues: 8
Max. Number of VLANs: 256
VLAN ID Range: VID 1 to 4094
IGMP Groups: 4096
MAC Table Size: 16 K
Packet Buffer Size: 12 Mbit
DRAM Size: 128 MB
Flash Size: 16 MB
Jumbo Frame Size: 9.6 KB
Interface
Gigabit Ethernet: 10/100/1000BaseT(X) or 100/1000BaseSFP slot
Console Port: USB-serial console (Type B connector)
Storage Port: USB storage (Type A connector for ABC-02-USB)
Alarm Contact: 1 relay output with current carrying capacity of 2 A @
30 VDC
Digital Inputs: 1 input with the same ground, but electrically isolated
from the electronics.
•+13to+30Vforstate“1”
•-30to+1Vforstate“0”
•Max.inputcurrent:8mA
Power Requirements
Input Voltage: 110 to 220 VAC
Operating Voltage: 85 to 264 VAC
Input Current: Max. 0.67/0.38 A @ 110/220 VAC
Overload Current Protection: Present
Reverse Polarity Protection: Present
Physical Characteristics
IP Rating: IP30 protection
Dimensions: 440 x 44 x 386.9 mm (17.32 x 1.73 x 15.23 in)
Weight: 5.1 kg (11.25 lb)
Installation: 19-inch rack mounting
Environmental Limits
Operating Temperature:
StandardModels:-10to60°C(14to140°F)
WideTemp.Models:-40to75°C(-40to167°F)
Storage Temperature:-40to85°C(-40to185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
Safety: UL 60950-1, EN 60950-1
EMC: EN 55022/24
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC61000-4-2ESD:Contact:4kV;Air:8kV
IEC61000-4-3RS:80MHzto1GHz:10V/m
IEC61000-4-4EFT:Power:2kV;Signal:1kV
IEC61000-4-5Surge:Power:2kV;Signal:1kV
IEC61000-4-6CS:Signal:10V
IEC 61000-4-8
Rail Traffic: EN 50121-4
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Note:PleasecheckMoxa’swebsiteforthemostup-to-datecerticationstatus.
MTBF (mean time between failures)
Time:
IKS-G6524A:460,854hrs
IKS-G6824A:471,418hrs
Standard: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
