4
Industry-specific Ethernet Switches
M12 Connectors
M12/M23 Power Cords
M12 IP67 Protective Caps
M23 Connectors
© Moxa Inc. All Rights Reserved. Updated Jun. 10, 2014. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
EN 50155 Switch Accessories
CBL-M12D(MM4P)/RJ45-100 IP67
1-meter M12-to-RJ45 Cat-5C UTP Ethernet cable with
IP67-rated 4-pin male D-coded M12 connector
M12D-4P-IP68
Field-installable M12 D-coded screw-in
sensor connector, 4-pin male, IP68-rated
A-CAP-M12F-M
Metal cap for M12 female connector
CBL-M23(FF6P)/Open-BK-100 IP67
1-meter M23-to-6-pin power cable with
IP67-rated 6-pin female M23 connector
A-PLG-WPM23-01
M23 cable connector, 6-pin female, crimp type
CBL-M12(FF5P)/OPEN-100 IP67
1-meter M12-to-5-pin power cable with IP67-rated
5-pin female A-coded M12 connector
M12A-5P-IP68
Field-installable M12 A-coded screw-in
sensor connector, 5-pin female, IP68-rated
A-CAP-M12M-M
Metal cap for M12 male connector
