- 14 -
a. 50/125 μm, 400 MHz * km or 62.5/125 μm, 500 MHz * km @ 850 nm
multimode fiber optic cable
b. 62.5/125 μm, 750 MHz * km @ 1310 nm multimode fiber optic cable
c. 9/125 μm single-mode fiber optic cable
NOTE
The actual communication distance depends on many factors,
including connector loss, cable deployment, and the age of the
cabling system. We recommend doing a link budget analysis and
reserving a 3 dB margin for such factors.
NOTE
Please refer to the SFP-1G Series datasheet for more detailed SFP
module specifications.
Power
Input Voltage
12-48 VDC, Class 2, redundant inputs
Input Current
0.229-0.068 A
Connection
Removable Terminal Block
Overload Current
Protection
2.5 A @ 25°C
Reverse Polarity
Protection
Present
Mechanical
Casing
IP30 protection, metal case
Dimensions (W x H x D)
53 x 135 x 105 mm (2.1 x 5.3 x 4.1 in)
Weight
630 g
Installation
DIN-rail or wall mounting (optional kit)
Environmental Limits
Operating Temperature
0 to 60°C (32 to 140°F),
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature
-40 to 85°C (-40 to 185°F)
Ambient Relative
Humidity
5 to 95% (non-condensing)
Regulatory Approvals
Safety
UL 508 (can be used in Pollution Degree 2
Environments)
EMI
FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 2
EN61000-4-6 (CS), Level 3
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
WARRANTY
5 years
