Moxa IMC-P101-M-ST [2/2] Ordering information

2

Ethernet Media Converters and Extenders

Ordering Information

Panel Mounting Kit (Optional)Rear ViewFront ViewSide View

Dimensions

Unit: mm (inch)

135.1 (5.32)

144.45 (5.69)

101.4 (3.99)

67 (2.64)

39.84 (1.57)

40.8 (1.61)

12.06

(0.47)

42.4 (1.67) 40 (1.57)

© Moxa Inc. All Rights Reserved. Updated Mar. 28, 2014. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Available Models

IMC-P101-M-SC: PoE industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode port with SC

connector, 0 to 60°C operating temperature

temperature

IMC-P101-M-ST-T: PoE industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode port with ST connector, -40 to 75°C operating

temperature

IMC-P101-S-SC-T: PoE industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode port with SC connector, -40 to 75°C operating

temperature

IMC-P101-S-ST-T: PoE industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode port with ST connector, -40 to 75°C operating

temperature

Optional Accessories (can be purchased separately)

WK-51: Wall mounting kit

Package Checklist

• 1 IMC-P101 media converter

Connection: Removable terminal block

Overload Current Protection: 1.6 A (protects against two signals

shorted together)

Reverse Polarity Protection: Protects against V+/V- reversal

Standards and Certifications

Safety: UL 508

EMC: CE, FCC

EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A

EMS:

IEC 61000-4-2 (ESD) Level 4,

Shock: IEC 60068-2-27

Freefall: IEC 60068-2-32

Vibration: IEC 60068-2-6

Green Product: RoHS, CRoHS, WEEE

MTBF (mean time between failures)

Time: 435,210 hrs

Database: Telcordia (Bellcore), GB

Warranty

Warranty Period: 5 years

Details: See www.moxa.com/warranty
