Ethernet Media Converters and Extenders
3
© Moxa Inc. All rights reserved. Updated Apr. 15, 2016. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
Ordering Information
Panel-Mounting Kit (Optional)
Top & Bottom ViewFront ViewSide View
PTC-101-M12
Dimensions
Unit: mm (inch)
101.4 (3.99)
103.4 (4.07)
10.5 (0.41)
135 (5.31)
144.8 (5.70)
66.78 (2.63)
161.14 (6.34)
144.64 (5.69)
34 (1.34)
51.6 (2.03)
185.14 (7.29)
Available Models
PTC-101-M-SC-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with SC connector,
dual redundant power inputs (20-72 VDC), -40 to 85°C operating temperature
PTC-101-M-ST-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with ST connector,
dual redundant power inputs (20-72 VDC), -40 to 85°C operating temperature
PTC-101-M-LC-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with LC connector,
dual redundant power inputs (20-72 VDC), -40 to 85°C operating temperature
PTC-101-S-SC-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with SC connector, dual redundant power inputs
(20-72 VDC), -40 to 85°C operating temperature
PTC-101-S-ST-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with ST connector, dual redundant power inputs
(20-72 VDC), -40 to 85°C operating temperature
PTC-101-S-LC-LV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with LC connector, dual redundant power inputs
(20-72 VDC), -40 to 85°C operating temperature
PTC-101-M-SC-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with SC connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-M-ST-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with ST connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-M-LC-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with LC connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-S-SC-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with SC connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-S-ST-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with ST connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-S-LC-HV: Industrial 10/100BaseT(X) to 100BaseFX media converter, single-mode with LC connector, 1 isolated power supply
(88-300 VDC or 85-264 VAC), -40 to 85°C operating temperature
PTC-101-M12-S-SC-LV-T: Industrial 10/100BaseT(X) to 100BaseFX media converter, M12 connector, single-mode with SC connector (20-72 VDC),
-40 to 85°C operating temperature
PTC-101-M12-S-ST-LV-T: Industrial 10/100BaseT(X) to 100BaseFX media converter, M12 connector, single-mode with ST connector (20-72 VDC),
-40 to 85°C operating temperature
PTC-101-M12-S-SC-LV-T-CT: Industrial 10/100BaseT(X) to 100BaseFX media converter, M12 connector, single-mode with SC connector (20-72 VDC),
-40 to 85°C operating temperature, conformal coating
PTC-101-M12-S-ST-LV-T-CT: Industrial 10/100BaseT(X) to 100BaseFX media converter, M12 connector, single-mode with ST connector (20-72 VDC),
-40 to 85°C operating temperature, conformal coating
Conformal coating: Available for PTC-101-M12 series
Optional Accessories (can be purchased separately)
WK-51: Wall-mounting kit
DK-DC50131: DIN-rail mounting kit
WK-51-01: DIN-rail/wall-mounting kit, 2 plates with 6 screws
DK-DC50131-01: DIN-rail mounting kit, 2 plates with 8 screws
Package Checklist
• 1 PTC-101 media converter
• Hardware installation guide
(printed)
• Warranty card
