LED Indicators
The front panel of the Moxa AWK-1127 contains several LED indicators.
The function of each LED is described in the table below.
LED
Color
State
Description
PWR Green
On
Power is on.
Off
Power is not being supplied
FAULT Red
On
System is booting up
Blinking
(slow at
1-second
intervals)
Cannot get an IP address from the
DHCP server.
Blinking
(fast at
0.5-second
interval)
IP address conflict.
Off
Status is normal.
STATE
Green/
Red
Green
System startup is complete and the
system is in operation.
Green
(Blinking at
1-second
intervals)
The device has been located by the
Wireless Search Utility.
Red
System is booting up.
SIGNAL
(5 LEDs)
Green
On
Signal level
Off
Reserved
WLAN Green
On
WLAN has been established.
Blinking
WLAN is transmitting data.
Off
WLAN is not working properly.
LAN Green
On
100/10 Mbps LAN port is active.
Blinking
Data is being transmitted.
Off
100/10 Mbps LAN port is inactive.
TX/RX
Green
On
Serial port is transmitting data.
Off
No data is being received through the
serial port.
Amber
On
Serial port is receiving data.
Off
No data is being transmitted through
the serial port.
Specifications
WLAN Interface
Standards
IEEE 802.11a/b/g for Wireless LAN
IEEE 802.11i for Wireless Security
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X)
IEEE 802.3af for Power-over-Ethernet (PoE models
Only)
IEEE 802.1D for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
