Industrial USB
1
www.moxa.com
UPort
®
2210/2410
2 and 4-port RS-232 USB-to-serial converters
The UPort® 2210/2410 USB-to-serial converters allow you to connect
2 or 4 RS-232 devices to your laptop or workstation through the USB
(Universal Serial Bus) port. The UPort® 2210 and UPort® 2410 are
cost-effective solutions for both new and legacy RS-232 devices, and
are perfect for mobile, instrumentation, and point-of sale applications.
Specifications
Overview
› Hi-Speed USB 2.0 for up to 480 Mbps USB transmission
› 921.6 kbps maximum baudrate for super fast data transmission
› Drivers provided for Windows and Linux
› Supports Fixed-Base COM Utility for setting the initial extended
COM port number
› LEDs for easy monitoring
USB Interface
Compliance: USB 1.1/2.0 compliant
Connector: USB type B
Speed: 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB)
Serial Interface
Number of Ports:
UPort 2210: 2
UPort 2410: 4
Serial Standards: RS-232
Connector: DB9 male
Performance
Baudrate: 50 bps to 921.6 kbps
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Mark, Space
Flow Control: RTS/CTS, XON/XOFF
I/O Address: Assigned by BIOS
IRQ: Assigned by BIOS
FIFO: 16 bytes
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Operating Systems
Windows Real COM Drivers: Windows 2000, Windows XP/2003/
Vista/2008/7/8/8.1 (x86/x64), Windows 2012 (x64)
Mac Driver: Mac OS X
Linux Real TTY Drivers: Linux 2.6.x, 3.x
Note: Please refer to Moxa’s website for the latest driver support information.
Physical Characteristics
Housing: Polycarbonate (PC)
Weight:
Product only:
UPort 2210: 120 g (0.26 lb)
UPort 2410: 210 g (0.46 lb)
Packaged:
UPort 2210: 325 g (0.72 lb)
UPort 2410: 455 g (1 lb)
Dimensions:
UPort 2210: 70 x 35 x 120 mm (2.76 x 1.38 x 4.72 in)
UPort 2410: 80 x 35 x 185 mm (3.15 x 1.38 x 7.28 in)
Environmental Limits
Operating Temperature: 0 to 55°C (32 to 131°F)
Storage Temperature: -20 to 75°C (-4 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 60950-1
EMC: CE, FCC
EMI: EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, FCC Part 15
Subpart B Class B
EMS: EN 55024, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC
61000-4-5, IEC-61000-4-6, IEC 61000-4-8, IEC-61000-4-11
Green Product: RoHS, CRoHS, WEEE
Power Requirements
Power Consumption:
UPort 2210: 140 mA @ 5 VDC
UPort 2410: 240 mA @ 5 VDC
MTBF (mean time between failures)
Time:
UPort 2210: 4,221,778 hrs
UPort 2410: 3,901,775 hrs
Database: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
