Moxa UPort 1650-16 [2/2] Ordering information

Industrial USB

2

© Moxa Inc. All rights reserved. Updated Mar. 12, 2015. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

Specifications

Ordering Information

Available Models

UPort 1610-16: 16-port RS-232 USB-to-serial converter

UPort 1650-16: 16-port RS-232/422/485 USB-to-serial converter

Optional Accessories (can be purchased separately)

Package Checklist

(UPort 1650-16 only)

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card

USB Interface

Compliance: USB 1.1/2.0 compliant

Connector: USB type B

Speed: 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB)

Serial Interface

Number of Ports: 16

Serial Communication Parameters

Data Bits: 5, 6, 7, 8

Stop Bits: 1, 1.5, 2

Parity: None, Even, Odd, Space, Mark

Flow Control: RTS/CTS, XON/XOFF

FIFO: 128 bytes

Serial Signals

RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

RS-422: TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND

RS-485-4w: TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND

Linux Real TTY Drivers: Linux 2.6.x, 3.x

Note: Please refer to Moxa’s website for the latest driver support information.

Physical Characteristics

Housing: SECC sheet metal (1 mm)

Weight:

Product only: 2475 g (5.45 lb)

Packaged: 3485 g (7.68 lb)

Dimensions: 440 x 45.5 x 198.1 mm (17.32 x 1.79 x 7.80 in)

Environmental Limits

Operating Temperature: 0 to 55°C (32 to 131°F)

Standards and Certifications

Safety: UL 60950-1

EMC: CE, FCC

EMI: EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, FCC Part 15

EMS: EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN

61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11

Green Product: RoHS, CRoHS, WEEE

UPort 1610-16: 130 mA @ 100 VAC

UPort 1650-16: 150 mA @ 100 VAC

Input Voltage: 100 to 240 VAC external power

MTBF (mean time between failures)

Time:

UPort 1610-16: 138,704 hrs

UPort 1650-16: 120,001 hrs
