Industrial USB
1
www.moxa.com
UPort
®
204/207
4 and 7-port entry-level USB hubs
Specifications
Electrostatic discharge (ESD) could be as severe as having more than
one thousand volts of ESD with a high rise time (dv/dt) break through
the junction layer of protective devices. In order to avoid serious
damage, Moxa’s UPort® 204/207 USB hubs provide ESD level 4
(contact 8 kV, air 15 kV) protection, which increases the quality and
value of the user’s end-product.
ESD Level 4 Protection
› Hi-Speed USB 2.0 for up to 480 Mbps of USB transmission
› USB-IF certification
› Compatible with USB 1.1 devices
› 15 kV ESD Level 4 protection for all USB ports
› Wall mountable
› Comprehensive diagnostic LEDs
› Full 500 mA of power per port
› Choose bus power or external power (UPort 204 only)
USB Interface
Compliance: USB 1.1/2.0 compliant
Upstream: 1 USB port (Type B connector)
Downstream:
UPort 204: 4 USB ports, Type A connectors
UPort 207: 7 USB ports, Type A connectors
Speed: 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB)
Supply Current: 500 mA max. per channel
Physical Characteristics
Housing: Polycarbonate (PC)
Weight: (product only)
UPort 204: 800 g (1.76 lb)
UPort 207: 875 g (1.93 lb)
Dimensions:
UPort 204: 70 x 35 x 120 mm (2.76 x 1.38 x 4.72 in)
UPort 207: 80 x 35 x 185 mm (3.15 x 1.38 x 4.72 in)
Environmental Limits
Operating Temperature: 0 to 60°C (32 to 140°F)
Storage Temperature: -20 to 75°C (-4 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 508, LVD
EMC: CE, FCC
EMI: EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, EN 61000-6-4, FCC
Part 15 Subpart B Class A
EMS: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6, EN 61000-4-8, EN 61000-4-11
Green Product: RoHS, CRoHS, WEEE
Power Requirements
Power Consumption:
UPort 204: 1210 mA @ 12 VDC, 610 mA @ 24 VDC, 430 mA @ 36 VDC
UPort 207: 2170 mA @ 12 VDC, 1070 mA @ 24 VDC, 730 mA @ 36 VDC
Input Voltage: 12 to 40 VDC external power
MTBF (mean time between failures)
Time:
UPort 204: 1,577,573 hrs
UPort 207: 1,059,201 hrs
Database: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
The UPort® 204 and UPort® 207 are entry-level USB 2.0 hubs
that expand 1 USB port into 4 and 7 USB ports, respectively. The
hubs are designed to provide true USB 2.0 Hi-Speed 480 Mbps data
transmission through each port, even for heavy-load applications. The
Introduction
UPort® 204/207 have received USB-IF Hi-Speed certification and are
fully Plug & Play. 500 mA of power per port ensures that your USB
devices will function properly and use of 12-40 VDC power makes
them ideal for mobile applications. Externally USB hubs provide a
broad USB device compatibility.
The UPort® 204/207 USB 2.0 entry-level USB hubs are USB-IF
(USB Implementers Forum) certified. USB-IF verifies a number of
strict electrical requirements for the Hi-Speed USB operation of USB
hubs designed to the USB 2.0 specification. This means that the
USB-IF Certification
UPort® 204/207 support Hi-Speed USB 2.0 for up to 480 Mbps USB
transmission (fully compliant with interoperability requirements) has
enough power for devices to function and provides for a successful
transition back to high-speed operation from the suspend state.
