Industrial USB
1
www.moxa.com
UPort
®
404/407
4 and 7-port industrial-grade USB hubs
Specifications
Electrostatic discharge (ESD) could be as severe as having more than
one thousand volts of ESD with a high rise time (dv/dt) break through
the junction layer of protective devices. In order to avoid serious
damage, Moxa’s UPort® 404/407 USB hubs provide ESD level 4
(contact 8 kV, air 15 kV) protection, which increases the quality and
value of the user’s end-product.
ESD Level 4 Protection
USB Interface
Compliance: USB 1.1/2.0 compliant
Upstream: 1 USB port, Type B connector
Downstream:
UPort 404: 4 USB ports, Type A connectors
UPort 407: 7 USB ports, Type A connectors
Speed: 480 Mbps (Hi-Speed USB) and 12 Mbps (Full-Speed USB)
Supply Current: 500 mA max. per channel
Physical Characteristics
Housing: Aluminum
Weight: (product only)
UPort 404: 850 g (1.87 lb)
UPort 407: 950 g (2.1 lb)
Dimensions:
UPort 404: 80 x 35 x 130 mm (3.15 x 1.38 x 5.12 in)
UPort 407: 100 x 35 x 192 mm (3.94 x 1.38 x 7.55 in)
Environmental Limits
Operating Temperature:
Standard Models: 0 to 60°C (32 to 140°F)
Wide Temperature Models: -40 to 85°C (-40 to 185°F)
Storage Temperature:
Standard Models: -20 to 75°C (-4 to 167°F)
Wide Temperature Models: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 508, LVD
EMC: CE, FCC
EMI: EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, EN 61000-6-4, FCC
Part 15 Subpart B Class A
EMS: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6, EN 61000-4-8, EN 61000-4-11
Green Product: RoHS, CRoHS, WEEE
Introduction
The UPort® 404 and UPort® 407 are industrial-grade USB 2.0 hubs
that expand 1 USB port into 4 and 7 USB ports, respectively. The
hubs are designed to provide true USB 2.0 Hi-Speed 480 Mbps data
transmission through each port, even for heavy-load applications. The
UPort® 404/407 have received USB-IF Hi-Speed certification, which
is an indication that both products are reliable, high quality USB 2.0
hubs.In addition, the hubs are fully compliant with the USB Plug &
Play spec and provide a full 500 mA of power per port, ensuring that
your USB devices will function properly. The UPort® 404/407 hubs’
support of 12-40 VDC power makes them ideal for mobile applications.
Externally powered USB hubs are the only way to guarantee the
broadest compatibility with USB devices.
The UPort® 404 and UPort® 407 USB 2.0 industrial-grade USB hubs
have passed USB-IF (USB Implementers Forum) certification. USB-IF
verifies a number of strict electrical requirements for the high-speed
USB operation of USB hubs designed to the USB 2.0 specification.
USB-IF Certification
This means that the UPort® 404/407 support Hi-Speed USB 2.0 for
up to 480 Mbps USB transmission, which is fully compliant with
interoperability requirements, is enough power for devices to function,
and provides for a successful transition back to high-speed operation
from the suspend state.
› Hi-Speed USB 2.0 for up to 480 Mbps USB transmission
› USB-IF certification
› Dual power inputs (power jack and terminal block)
› 15 kV ESD Level 4 protection for all USB ports
› Rugged metal housing
› DIN-Rail and wall mountable
› Comprehensive diagnostic LEDs
› Choose bus power or external power (UPort 404)
