Moxa CP-104EL-A-DB9M [2/2] Ordering information
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

Moxa CP-104EL-A-DB9M [2/2] Ordering information

Moxa CP-104EL-A-DB9M [2/2] Ordering information
PIN RS-232
1 DCD
2 RxD
3 TxD
4 DTR
PIN RS-232
2 TxD
3 RxD
4 RTS
5 CTS
PIN RS-232
5 GND
6 DSR
7 RTS
8 CTS
PIN RS-232
6 DSR
7 GND
8 DCD
20 DTR
CBL-M44M9x4-50
DB44 male to DB9 male x 4 (50 cm cable)
DB9 male
CBL-M44M25x4-50
DB44 male to DB25 male x 4 (50 cm cable)
DB25 male
Available Models
CP-104EL-A-DB9M: 4-port RS-232 PCI low profile Express x1 serial
board (includes DB9 male cable)
CP-104EL-A-DB25M: 4-port RS-232 low profile PCI Express x1 serial
board (includes DB25 male cable)
Connection Options (can be purchased separately)
Package Checklist
• 1 CP-104EL-A board
• DB9-M or DB25-M connection cable
• Standard bracket and low profile bracket
• Documentation and software CD
• Quick installation guide (printed)
• Warranty card
Standards and Certifications
EMC: CE, FCC
EMI: EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B
Class B
EMS: EN 55024, EN 61000-6-2, EN 61000-6-4, IEC 61000-4-2, IEC
61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC
61000-4-8, IEC 61000-4-11 (DIPS)
Green Product: RoHS, CRoHS, WEEE
MTBF (mean time between failures)
Time: 7,723,378 hrs
Database: Telcordia (Bellcore), GB
Power Requirements
Power Consumption: 805 mA @ 3.3 V
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Ordering Information
1
13
14 25
1
5
6 9
Dimensions
Unit: mm (inch)
MUE450
TX2
RX1 RX2
Tx3
Rx3
Tx4
Rx4
TX1
CP-104EL-A
63.58 (2.5)
80 (3.15)
54.45 (2.15)
67.21 (2.65)
59.05 (2.33)
103 (4.06)
116.77 (4.6)
2
Multiport Serial Boards
