Power Computers
3
www.moxa.com
Software Specifications
Linux
OS: Linux Debian 8, 64-bit
Terminal Server (SSH): Provides secure encrypted communications
between two un-trusted hosts over an insecure network
Kernel Version: GNU/Linux 3.16
System Shell: DASH (default), BASH
File System: EXT2, EXT3, EXT4
Internet Protocol Suite: TCP, UDP, IPv4, IPv6, SNMPv2, ICMP, ARP,
HTTP, CHAP,PAP,DHCP, NTP,NFS, SSH, PPP, SFTP, RSYNC, SSL
Programming Language Support: PHP, Perl, Python
Internet Security Suite: OpenVPN, iptables
Secure Shell for Remote Access: SSH allows remote logins to a
secure encrypted console from any connected network
Watchdog: Features a hardware function to trigger system reset in a
user specified time interval (Linux standard API)
Windows Embedded Standard 7 (by CTOS)
Core OS:
• Windows 7 Embedded, 32-bit/64-bit
• Sensor and Location Platform
• Remote Procedure Call
Applications and Services Development:
• .Net Framework 3.5
• Remote Desktop Protocol 7.1
• COM OLE Application Support
• COM+ Application Support
• MSMQ
Internet Services:
• Internet Explorer 8.0
• IIS 7.0
File Systems and Data Storage:
• Windows Data Access Components
• Windows Backup and Restore
Diagnostics:
• Common Diagnostic Tools
• Problem Reports and Solutions
Fonts:
• Chinese (Trad. and Simp.), Middle East, South East Asian, South
Asian Fonts
• True Type Fonts
Graphics and Multimedia:
• MPEG DTV-DVD Audio Decoder (MPEG-2, AAC)
• MPEG Layer-3 Audio Codecs(MP3)
• MPEG4 Decoders
• Windows Media Video VC-1 (WMV) Codecs
• DirectX and Windows Device Experience
• Windows Media Player 12
Dimensions
Unit: mm (inch)
440 (17.32)
440.1 (17.33)
417 (16.42)
462.6 (18.21)
480 (18.9)
5.6 (0.22)
31.8 (1.25)
315 (12.4)
221.4 (8.72)
24.2 (0.95)
44 (1.73)
6.3 (0.25)
Standards and Certifications
Safety: LVD, UL, cUL
Electrical Substation: IEC 61850-3, IEC 60255, IEEE 1613
Protection Relay: IEC 60255
EMC: FCC, CE (Class A)
Green Product: RoHS, CRoHS, WEEE
Reliability
Alert Tools:
• Built-in buzzer and RTC (real-time clock) with battery lithium backup
• Built-in 1 relay for visual/audio alarm.
Automatic Reboot Trigger: Built-in watchdog timer, configurable for
restarts at 1 to 255 second intervals
MTBF (mean time between failures):
DA-681A-I-SP: 240784 hrs
DA-681A-I-DPP: 215436 hrs
DA-681A-I-DPP-T: 215436 hrs
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
