Moxa DA-681A-I-DPP-LX [4/5] Ordering information
![Moxa DA-681A-I-DPP-LX [4/5] Ordering information](/views2/1198895/page4/bg4.png)
Power Computers
4
www.moxa.com
Recommended Configurations
Operating System System Memory mSATA for OS
Windows Embedded Standard 7 32 bit
≥ 4 GB ≥ 8 GB
Windows Embedded Standard 7 64 bit
≥ 4 GB ≥ 16 GB
Linux Debian 8
≥ 2 GB ≥ 4 GB
Ordering Information
Management:
• Group Policy Management
• Windows Management Instrument (WMI)
• Windows Update
Networking:
• Extensible Authentication Protocol (EAP)
• Internet Authentication Service
• Telnet Server
• Bluetooth
• Domain Services
• Network Access Protection
• Network and Sharing Center
• Quality of Service
• Remote Access Service (RAS)
• Telephony API Client
• Windows Firewall
• Wireless Networking
Security:
• Credential Roaming Service
• Credentials and Certicate Management
• Windows Authorization Manager (AZMAN)
• Windows Security Center
• Active Directory Rights Management
• Security Base
• Encrypted File System (EFS)
Embedded Features:
• Enhanced Write Filter (EWF)
• File-Based Write Filter (FBWF)
• Message Box Default Reply
• Registry Filter
• WSDAPI for .NET
Embedded Self-Health Diagnostics:
SNMP-based remote scripting layer for monitoring, reporting, and
control
Package Checklist
• DA-681A rackmount computer
• Rackmount kit
• Documentation CD or DVD
• Quick installation guide (printed)
• Warranty card
Available Models
DA-681A-I-SP: 6 Ethernet ports, VGA, 2 RS-232/422/485 ports, 10 RS-485 ports, mSATA, SATA, USB,
Single Power (RAM, mSATA, OS not included), -25 to 55°C operating temperature
DA-681A-I-SP-LX: 6 Ethernet ports, VGA, 2 RS-232/422/485 ports, 10 RS-485 ports, mSATA, SATA, USB,
Single Power, Linux Debian 8., -25 to 55°C operating temperature
DA-681A-I-DPP: IEC 61850-3 computer with VGA, 6 LAN ports, 2 RS-232/422/485 ports, 10 RS-485
ports, mSATA, SATA, USB, dual power (RAM, mSATA, OS not included), -25 to 55°C operating
temperature
DA-681A-I-DPP-LX: IEC 61850-3 computer with VGA, 6 LAN ports, 2 RS-232/422/485 ports, 10 RS-485 ports, mSATA, SATA, USB, dual power, Linux
Debian 8, -25 to 55°C operating temperature
DA-681A-I-DPP-T: IEC 61850-3 computer with VGA, 6 LAN ports, 2 RS-232/422/485 ports, 10 RS-485 ports, mSATA, SATA, USB, dual power (RAM,
mSATA, OS not included), -40 to 70°C operating temperature
DA-681A-I-DPP-T-LX: IEC 61850-3 computer with VGA, 6 LAN ports, 2 RS-232/422/485 ports, 10 RS-485 ports, mSATA, SATA, USB, dual power,
Linux Debian 8, -40 to 70°C operating temperature
Note: To order a DA-681A system with a pre-installed W7E OS, please contact a Moxa sales representative.
