DA-682A-DPP Linux Software Software Configuration
2-4
Windows Users
The most popular SSH client for the Windows platform is the freely available PuTTY program. To download
PuTTY, visit
http://www.chiark.greenend.org.uk/~sgtatham/putty/download.html. After
installing PuTTY, Windows users will be able to access the DA-682A-DPP computer using SSH. The following
screen shows the setup of a sample PuTTY session.
Linux Users
Linux users can run the ssh command from the console. The following command logs a user in over LAN1:
moxa@Moxa:~#ssh 192.168.3.127
user@remoteDebian-moxa@Moxa:~# ssh 192.168.3.127
The authenticity of host ‘192.168.3.127 (192.168.3.127)’ can’t be established.
RSA key fingerprint is 8b:ee:ff:84:41:25:fc:cd:2a:f2:92:8f:cb:1f:6b:2f.
When asked if you want to continue connecting over SSH, answer yes by typing Y, y, or yes.
Are you sure you want to continue connection (yes/no)? yes_
