DA-685 Linux Introduction
1-2
Overview
Pre-installed with Linux, the DA-685 Series provides programmers with a friendly environment for developing
sophisticated, bug-free application software at a lower cost.
The DA-685's DPP-T models support a wide operating temperature range of -40 to 70°C for use in harsh
industrial environments.
Software Specifications
The Linux operating system pre-installed on the DA-685 embedded computer is the Debian Lenny
5.0 distribution. The Debian project is a worldwide group of volunteers who endeavor to produce an operating
system distribution that composed entirely of free software. The Debian GNU/Linux follows the standard Linux
architecture, making it easy to use programs that meet the POSIX standard. Program porting is possible with
the GNU Tool Chain provided by Moxa. In addition to Standard POSIX APIs, device drivers for Moxa UART and
other special peripherals are also included. The following is a software architecture example:
ATTENTION
Refer to http://www.debian.org/ and http://www.gnu.org/ for information and documentation of the Debian
GNU/Linux and free software concept.
ATTENTION
The above software architecture is only an example. Different models or different build revisions of the Linux
operating system may include components not shown in the above graphic.
Software Components
The DA-685-LX pre-installed Debian Lenny 5.0 Linux distribution. For the software components, see Appendix
A.
RS-232, Ethernet, CompactFlash, SATA, USB
Memory Control, Schedule, Process
CF, USB, UART, RTC, VGA
TCP, IP, UDP, CMP, ARP, HTTP, SNMP, SMTP
Daemon (Apache, Telnet, FTPD)
Application Interface (POSIX, Socket, Secure Socket)
User Applications
File
System
Hardware
Micro Kernel
Device Driver
Protocol
Stack
API
AP
Linux
Kernel
