Compact/Fanless Computers
1
www.moxa.com
V2201 Series
Fanless, ultra-compact, rugged x86 IIoT embedded computer
The Moxa V2201 series ultra-compact x86 embedded computer is
based on the Intel® Atom™ E3800 series processor, features the
most reliable I/O design to maximize connectivity, and supports
dual wireless modules, making it suitable for a diverse range of
communication applications. The computer’s thermal design ensures
reliable system operation in temperatures ranging from -40 to 85°C
(-40 to 70°C with a special purpose Moxa wireless module installed).
The V2201 series supports “Moxa Hardware Monitoring” for device
I/O status monitoring and alerts, system temperature monitoring and
alerts, and system power management. Monitoring system status
closely makes it easier to recover from errors and provides the most
reliable platform for your applications.
Applications:
• Remote Terminal Unit (RTU)
• Data acquisition
• M2M communication (smart gateway)
• Digital signage
• Factory automation
• In-vehicle monitor/data logger (transportation)
• Programmable router
• Energy usage optimization
• Predictive maintenance
• Asset management
Overview
Front View
Appearance
› Intel Atom E3800 series processor with three performance options
› -40 to 85°C system operating temperature (-40 to 70°C with LTE
module installed)
› Dual mini-PCIe sockets for wireless modules, supports W-iFi, 3G,
LTE, GPS, and Bluetooth
› Variety of interfaces: 2 serial ports, 2 Ethernet LAN port, 4 DIs, 4
DOs, SD, USB, HDMI, wireless
› EN 61000-6-2 and EN 61000-6-4 certification*; meets EMC standard
for heavy industry
› Up to 5 Grms anti-vibration and 100 g/11 ms anti-shock
› Ready-to-run Debian 8 and Windows Embedded Standard 7 platforms
› Moxa Proactive Monitoring utility for system hardware health
monitoring
› Moxa Smart Recovery utility to recover system from boot failure
(W7E only)
*Passed with AC/DC adapter.
Left Side View
Right Side View
Wi-Fi Antenna
Connector (SMA)
HDMI
(Type A)
USB Hosts x 2
(Type A)
3G/LTE Antenna
Connector (SMA)
LED Indicators x 10
3G/LTE Antenna
Connector (SMA)
Wi-Fi Antenna
Connector (SMA)
Power Button
Grounding Screw
(M4)
DI x 4
10/100/1000 Mbps
LAN Ports x 2 (RJ45)
DO x 4
Power Input
(3-pin terminal block)
Serial Ports x 2
(DB9)
GPS Antenna
Connector (SMA)
USB 3.0 Hosts x 1
Up: SDHC/SDXC Slot
Down: USIM Card Slot
