Compact/Fanless Computers
2
www.moxa.com
Hardware Specifications
Computer
CPU:
V2201-E1 Series: Intel® Atom™ Processor E3815 (Single Core, 512K
Cache, 1.46 GHz)
V2201-E2 Series: Intel® Atom™ Processor E3826 (Dual Core, 1M
Cache, 1.46 GHz)
V2201-E4 Series: Intel® Atom™ Processor E3845 (Quad Core, 2M
Cache, 1.91 GHz)
OS: Windows Embedded Standard 7 64-bit or Linux Debian 8 64-bit
System Memory: 1 DDR3 SO-DIMM slot, 8 GB max.
•E3815andE3826supportDDR3L-1066
•E3845supportsDDR3L-1333
USB: 1 bootable USB 3.0 port, 2 bootable USB 2.0 ports (type A)
Storage
mSATA: 1 internal mini-PCIe socket for OS storage
SD: 1 SD 3.0 (SDHC/SDXC) socket for storage expansion*
*W7E only supports SD 2.0
Audio
Output: Line-out interface (together with HDMI)
Other Peripherals
Expansion Slot: 2 Mini-PCIe sockets
•1USBsignal,forSierraWireless3G/LTEmodule
•1USB+PCIesignal
USIM: 1 USIM slot
Display
Graphics Controller: Intel® HD (integrated)
Connector Type: 1 HDMI connector (type A)
Display Interface: Supports HDMI 1.4a, 1920 x 1080 pixels @ 60/24 Hz
Ethernet Interface
LAN: Auto-sensing 10/100/1000 Mbps ports (RJ45) x 2
Isolation Protection: 1.5 kV
Wireless SMA Interface
Wi-Fi: 2 SMA connectors
3G/LTE: 2 SMA connectors
GPS: 1 SMA connector
Serial Interface
Serial Standards: RS-232/422/485 software selectable ports (DB9 male)
x 2
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF
Baudrate: 50 bps to 115.2 kbps
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422:TxD+,TxD-,RxD+,RxD-,GND
RS-485-4w:TxD+,TxD-,RxD+,RxD-,GND
RS-485-2w:Data+,Data-,GND
Digital Input
Input Channels: DI x 4
Input Voltage: 0 to 30 VDC at 25 Hz
Digital Input Levels for Dry Contacts:
Logic level 0: Close to GND
Logic level 1: Open
Digital Input Levels for Wet Contacts:
Logiclevel1:+3Vmax.
Logiclevel0:+10Vto+30V(SourcetoDI)
Connector Type: 10-pin screw-fastened Euroblock terminal
Isolation: 3 kV optical isolation
Digital Output
Output Channels: DO x 4, sink type
Output Current: Max. 200 mA per channel
On-State Voltage: 24 VDC nominal, open collector to 30 VDC
Connector Type: 10-pin screw-fastened Euroblock terminal
Isolation: 3 kV optical isolation
LEDs
System: Power, user-defined
Storage: mSATA, SD
LAN: 2 LEDs per port (100/1000 Mbps)
Serial: 2 LEDs per port (Tx and Rx)
Wireless: Mini-PCIe 1, Mini-PCIe 2
Switches and Buttons
Power Switch: on/off (left-side panel)
Reset Button: For warm reboot (left-side panel)
Physical Characteristics
Housing: Aluminum
Weight: 940 g (2.09 lb)
Dimensions:
Without ears: 150 x 48.8 x 120.2 mm (5.91 x 1.92 x 4.73 in)
With ears: 178 x 52.5 x 120.2 mm (7.01 x 2.07 x 4.73 in)
Mounting: DIN rail, wall
Environmental Limits
Operating Temperature:
•E1/E2models:-40to85°C(-40to185°F)
•E4models:-40to70°C(-40to158°F)
•E1-W/E2-W/E4-WmodelswithMoxarecommendedwireless
modules(3G/LTE+Wi-Fi)installed:-40to70°C(-40to158°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Anti-Vibration: IEC 60068-2-64: 5 Grms, 5 Hz to 500 Hz, 1 hr/axis w/
mSATA, SD
Anti-Shock: IEC 60068-2-27: 100 g/11 ms ±X, ±Y, ±Z, 3 shocks each
axis w/ mSATA, SD
Power Requirements
Input Voltage:9to36VDC(3-pinterminalblockforV+,V-,SG)
Input Current: 2 A @ 9 VDC
Power Consumption: 18 W
Standards and Certifications
Safety: UL 60950-1, CSA C22.2 No. 60950-1-03 (60950-1-07), EN
60950-1, UL 508
EMC: EN 55022/24, EN 61000-6-2/6-4*
*Passed with AC/DC adapter.
EMI: CISPR 22, FCC Part 15B Class A
EMS:
IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m
IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV
IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV
IEC 61000-4-6 CS: 10 V
IEC 61000-4-8
Green Product: RoHS, CRoHS, WEEE
Reliability
Automatic Reboot Trigger: Software-programmable watchdog timer
configurable from 1 to 255 seconds
MTBF (mean time between failures)
Time: 408,275 hrs
Standard: Telcordia (Bellcore) Standard TR/SR
Warranty
Warranty Period: 3 years
Details: See www.moxa.com/warranty
Note: These hardware specifications describe the embedded computer unit itself,
but not its official accessories. In particular, the wide temperature specification
does not apply to accessories such as power adapters and cables.
