www.moxa.com

info@moxa.com

Compact/Fanless Computers

x86 ready-to-run embedded computers with Intel Atom N270, VGA,

DVI-I, audio, 2 Gigabit LANs, 4 serial ports, 4 DIs, 4 DOs, 6 USB 2.0

ports, CompactFlash, 2 peripheral expansion slots

The V2422 Series embedded computers are based on the Intel Atom

N270 x86 processor, and feature 4 RS-232/422/485 serial ports,

dual Gigabit LAN ports, and 6 USB 2.0 hosts. In addition, the V2422

computers provide VGA and DVI-I outputs, making them particularly

well-suited for railway and industrial applications.

The dual 10/100/1000 Mbps Ethernet ports offer a reliable solution

for network redundancy, promising continuous operation for data

communication and management. As an added convenience, the

V2422 computers have 4 DIs and 4 DOs for connecting digital input/

output devices. In addition, the CompactFlash socket, SATA connector,

and USB sockets provide the V2422 computers with the reliability

Front View

needed for industrial applications that require data buffering and

storage expansion. Moreover, the V2422 computers come with 2

peripheral expansion slots for inserting different communication

modules, such as a 2-port CAN module, an HSDPA, GPS, WLAN

module, an 8+8 port digital input/output module, a 2-port serial

module, a mini PCI expansion module, and a PCI Express module,

providing greater flexibility for setting up different industrial

applications at field sites.

Pre-installed with Linux or Windows Embedded Standard 2009, the

V2422 Series provides programmers with a friendly environment for

developing sophisticated, bug-free application software at a low cost.

V2422 Series

Overview

Appearance

› Intel Atom N270 1.6 GHz processor

› DDR2 SO-DIMM socket supporting DDR2 533 up to 2 GB (max.)

› Dual independent displays (VGA + DVI-I)

› 2 10/100/1000 Mbps Ethernet ports

› 4 RS-232/422/485 serial ports (non-standard baudrates

supported)

› 6 USB 2.0 ports for high speed peripherals

› 4 DIs, 4 DOs

› CompactFlash socket for storage expansion

› 1 SATA-II connector for hard disk drive expansion

› Ready-to-run Embedded Linux, or Windows Embedded Standard

2009 platform

CompactFlash

Socket

VGA

Output

DVI-I

Output

Expansion SlotPower Switch

Audio Input

Output

10/100/1000 Mbps

LAN Port x 2 (RJ45)

PS/2

USB 2.0 Host x 4

(type A)

Expansion Slot

System LEDs

(Power, Storage)
