Compact/Fanless Computers
Rear View
Hardware Specifications
Computer
CPU: Intel Atom N270 1.6 GHz processor
OS (pre-installed): Linux or Windows Embedded Standard 2009
System Chipset: Intel 945GSE + ICH7-M
BIOS: 8 Mbit Flash BIOS, PLCC type, ACPI function supported
FSB: 533 MHz
System Memory: 2 GB capacity, 1 GB pre-installed: 1 slot of 2 GB
DDR2-533 200 pin SO-DIMM SDRAM
Expansion Bus: PCI interface reserved
USB: USB 2.0 compliant hosts, type A connector x 6, supports system
boot up
Storage
Built-in: 2 GB onboard industrial DOM to store OS
Storage Expansion: CompactFlash socket for CF card expansion,
supporting CF Type-I/II
HDD Support: 1 SATA-II connector for HDD expansion
Other Peripherals
KB/MS: 1 PS/2 interface supporting standard PS/2 keyboard and
mouse through Y-type cable
Audio: Line-in, line-out interface
Display
Graphics Controller: Intel Gen 3.5 Integrated Graphics Engine, 250
MHz core render clock and 200 MHz core display clock at 1.05-V core
voltage
VGA Interface: DB15 female connector, up to 2048 x 1536 resolution
DVI Interface: DVI-I connector (chrontel CH7307 SDVO to DVI
transmitter), up to 1600 x 1200 resolution
Ethernet Interface
LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 kV
Serial Interface
Serial Standards:
4 RS-232/422/485 ports*, software selectable (DB9 male)
*COM1’s pin 9 signal can be set as N/C (default), +5 V, or +12 V by jumper
ESD Protection: 8 kV for all signals
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 kbps (non-standard baudrates supported;
see user’s manual for details)
USB 2.0
Host x 2 (type A)
Serial Port x 4
(RS-232/422/485, DB9 male)Power Input
Serial LED
(Tx/Rx x 4)
DI x 4
DO x 4
Reset Button
275 (10.83)
262.5 (10.33)
86 (3.39)
154 (6.06)
6 (0.24)
85.75 (3.38)
Dimensions
Unit: mm (inch)
