Power Computers
3
www.moxa.com
DA-SW08-RJ Hardware Specifications
DA-UPCI-DK Hardware Specifications
Ethernet Interface
LAN: 8 auto-sensing 10/100 Mbps unmanaged Ethernet switch ports
(RJ45)
Magnetic Isolation Protection: 1.5 kV built-in
Universal PCI Expansion Adatpor
PCI Slots: 1
Interface Bus: 32-bit Universal PCI (3.3 V and 5 V)
DA-LN04-RJ Hardware Specifications
DA-SP38-I-TB Hardware Specifications
Ethernet Interface
LAN: 4 auto-sensing 10/100 Mbps ports (RJ45)
Magnetic Isolation Protection: 1.5 kV built-in
Serial Interface
Serial Standards: 8 RS-422/485 ports, software selectable (DB9 male
or terminal block connector)
ESD Protection: 15 kV for all signals
Isolation: 2 kV digital isolation
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
Physical Characteristics
Weight: 245 g
Dimensions: 130 x 150 x 42 mm (5.12 x 5.91 x 1.65 in)
DA-SP08-DB, DA-SP08-I-DB, DA-SP08-I-TB Hardware Specifications
Serial Interface
Serial Standards: 8 RS-232/422/485 ports, software selectable (DB9
male or terminal block connector)
ESD Protection: 15 kV for all signals
Isolation: 2 kV digital isolation (DA-SP08-I-DB and DA-SP08-I-TB
only)
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
Physical Characteristics
Weight: 290 g
Dimensions: 130 x 150 x 42 mm (5.12 x 5.91 x 1.65 in)
MTBF (mean time between failures): 1,753,143 hrs
DA-SP08-I-EMC4-DB/TB Hardware Specifications
Serial Interface
Serial Standards: 8 RS-232/422/485 ports, software selectable (DB9
male or terminal block connector)
ESD Protection: 8 kV contact, 15 kV air
Surge Protection: 2 kV line-to-line and 4 kV line-to-ground surge
protection, 8/20 µs waveform
Insulation: 500 V
Isolation: 2 kV digital isolation
Pull low/high: 1k/150k, jumper selectable
Termination Resistor: 120 ohms, jumper selectable
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction
control) for RS-485
Baudrate: 50 bps to 921.6 kbps (supports non-standard baudrates;
see user’s manual for details)
Serial Signals
RS-232: TxD, RxD, RTS, CTS, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w: Data+, Data-, GND
Physical Characteristics
Weight: 500 g
Dimensions: 130 x 150 x 42 mm (5.12 x 5.91 x 1.65 in)
MTBF (mean time between failures): 1,753,143 hrs
Physical Characteristics
Weight: 198 g
Dimensions: 132 x 150 x 42 mm (5.20 x 5.91 x 1.65 in)
Physical Characteristics
Weight: 200 g
Dimensions: 132 x 150 x 42 mm (5.20 x 5.91 x 1.65 in)
Physical Characteristics
Weight: 195 g
Dimensions: 132 x 150 x 42 mm (5.20 x 5.91 x 1.65 in)
MTBF (mean time between failures): 11,053,266 hrs
